Pm Stainless Steel Bulkhead Union Air Hose Pipe Connector for Nylon Tube

Model NO.	SSB
Type	Quick Connector
Usage	Air Compressor
Brand	Smartsolu
Work Temperature	Normal Temperature
Material	Stainless Steel
Color	Blue, White, Yellow, Red, Orange
Size	4 to 16mm
Thread	M5 to 1/2"
Shape	T, L, V, E, Y, W
Transport Package	PP Bag
Specification	50PCS
Trademark	SMARTSOLU
Origin	China
HS Code	39174000
Production Capacity	10, 000, 000

Product Description
1  One-Touch push-to-connect configuration allows an instant tubing connection
2  Smooth-Edge release sleeve design facilitates a quick tubing disconnection
3   Aesthetically pleasing nickel-plated metallic optional feature ensures anti-
    corrosion and anti-containation properties of an extended product life
4  Pre-applied sealant on all external threads eliminates the additional sealing
    requirement
5  Internal and/of external flat-to-flat hexagonal configurations for both metric and
    inch specifications allow a proper tightening or directional orientation upon
    installation by using L key or allen wrench for the applicable model types



Model(φD) Tube(matric) SSB04-G01SSB08-G03SSB12-G03 SSB04-G02SSB08-G04SSB12-G04 SSB06-G01SSB10-G01SSB14-G02 SSB06-G02SSB10-G02SSB14-G03 SSB06-G03SSB10-G03SSB14-G04 SSB06-G04SSB10-G04SSB16-G02 SSB08-G01SSB12-G01SSB16-G03 SSB08-G02SSB12-G02SSB16-G04


Typical Application:
Air brake systems except where temperatures exceed +200°F tubing.
Or where battery acid can drip on
Operating pressure range:
(0 psi to 217.5 psi) (0 MPA to 1.5MPA)
Proof Pressure:
Maximum operating pressure of 261 psi
Vibration:
fair resistance
Operating Temperature Range:
(64°F  to  284°F)(-20ºC to  140ºC)
Fluid temperature:
(23°F  to  302°F)(-5ºC to  150ºC)
Application tubing:
Metric size ,Inch size
Connection thread:
M,R,RC,UNF,NPT
Material:
316 stainless steel
Advantages:
Easy to assemble (no TUBE preparation of flaring required.)built in TUBE support
This matric can ensures Anti-Corrosion and acid resistant ,also can be used in high temperature.
Grease-free/Can be used with steam
Certified to meet current
Food Sanitation Law standards .
(component materials have met apparatuses and container-packages standards)

• Stainless steel 316 one-touch fittings, inch size
• Seal parts:  FKM
• Can be used with steam
• Grease-free
•
  (component materials have met apparatuses and container-packages standards)
  Why choose us? (1) Quality, we only produce top-level quality products, we promise that all of our product's raw material are first class, and good quality system controls, so our goods' quality is very good.

  (2) Price, our policy is that "Win-to-Win". That means in view of our long-standing business relationships, we only take small profit to help you for the marketing.

  (3) Delivery, we alway have some products in stock, so we can complete the delivery within the time stipulated before.

  (4) No MOQ, I think it is an attractive condition to some of you who have no big demands for each items temporarily.


             *ISO Standard Cylinder:DNC/SI(ISO6431&6432)
             *Standard Cylinder:SC/SU,
             *Mini Cylinder:MAL,MA,,MI,CJ2B,CDM2B
             *Compact Cylinder:SDA,CQ2
             *Cylinder:CU,TN,STM,MGP
             *Solenoid Valve:3v1,3v,4v,4M,3A,4A ,drain valve etc
             *Air Source Treatment Unit:A,HA,HNA,T,A/B,etc
             *pneumatic accessories:fitting,hand valve,muffler,tube,pressure switch
             *Pneumatic Vibrator:GT,K,R,SK,FP,NTP etc.

  NINGBO HI-TECH SMART MACHINERY CO LTD was established in 2013, is a high tech company specialized in pneumatic components and microduct accessories manufacturing. After years' hard working, it has owned 2 factories now, and the products include pneumatic vibrators, air cylinders, solenoid valves, air treatment units, pneumatic fittings&mufflers, microduct connectors and other accessories. We have sold our goods to more than 60 countries, and that number is still increasing.Applicable tubing material includes FEP, PFA, nylon, soft nylon, polyurethane, polyolefin
