DIN 8077/8088 PPR Pipes and Fittings Pn20 Pn25 20X2.8mm 20X3.4mm for Water Supplying

Model NO.	PN16 PN20 PN25
Material	PPR
Kind	Thermoplastics Pipes
Water Absorption	0.2%~0.4%
Contraction Percentage	1.0%~2.5%
Tensile Strength	41~50MPa
Standard	DIN8077/8078
Certification	CE, GOST-R, ISO
Colour	White/Grey/Green
Size	16mm-110mm
Lenger	4 Meters/PC
Applications	Water Systems
Material Brand	Hyosung
Packing	PP Bags/ Plactis Bags
Transport Package	Cartons by Sea or Air
Specification	PN10, PN16, PN20, PN25
Trademark	ASB/OEM
Origin	China
HS Code	39172200
Production Capacity	50 Million Meters/Year

Product Description

ASB PP-R Pipes are made of 100% new material such as TAIRIPRO, SINOPEC and HYOSUNG. ASB is totally following the Germany Standard DIN8077/8088 to process the Pipes. Now the Pipe series is from PN12.5 to PN25 and the dimension is from 20mm to 110mm. With the advantages like lightness, corrosion resistance and long life, ASB PP-R Pipes are accepted by customers from over 90 countries in the world.

DimensionAverage DimensionPipe Series S5S4S3.2S2.5 PN12.5barPN16barPN20barPN25bar dndn,mindn,maxThickness 2020.020.32.02.32.83.4 2525.025.32.32.83.54.2 3232.032.32.93.64.45.4 4040.040.43.74.55.56.7 5050.050.54.65.66.98.3 6363.063.65.87.18.610.5 7575.075.76.88.110.312.5 9090.090.98.210.112.315.0 110110.0111.010. 012.315.118. 3

UnitPropertyValue ºCWorking Temperature0-95 w/m.kThermal Conductivity 0.21 mm(m.k)Thermal Expansion Coefficient 0.16 %Longitudinal Retraction Rate(135ºC/1h)≤3 g/10minMFR (230ºC/2.16kg)<0.5g/10min g/cmDensity0.94 MpaTensile Yield Strength≤40 %Elongation>50 MpaElasticity Modulus800 %Impact Test(0ºC;2h;15J)≤10

1-Good Appearance and Light Weight

The inner and outer walls of the product are smooth, the fluid resistance is small, the color is soft, the shape is beautiful, and the weight is only about 1/8 of the metal tube, which is convenient for transportation and installation.

2-Long Life
High pressure-resistant and high temperature resistant. ASB PP-R Pipe's life can be 50 years under normal conditions.

3-Hygiene
Green building materials, non-toxic, non-polluting, recyclable, not only for hot and cold water pipes but also for potable water systems

4-Good Thermostabilization
The Vicat softening point of the ASB PP-R pipe is 131.5ºC, it can be used for a long time when the working water temperature is 70 ºC, meeting the requirements of the hot water system in a real building.

5-Insulation and Energy Saving
The Thermal Conductivity of the ASB PP-R Pipe is only 0.21w/m.k, just 1/200 of the steel pipe
6-Easy installation
Using a hot-melt connection, a joint connection can be completed in several seconds. The pipe and fittings are made of the same type of raw material and the pipe-fitting joints reach the molecular level fusion, making it a whole system perfectly.


ASB PPR water pipes are inspected from the materials to finished products, we testing the MTR, Hardness, Hydrostatic pressure and burst pressure, etc to make sure the quality is at the top level

1.Residential Apartments
2.Hospital, Hotel, School, Office, Public Places, etc.

3.Hot and Cold Water System, Potable Water System

4.Solar System

5.Rainwater Pipe Network

6.Swimming Pool Pipe Network

7.Agriculture, Garden Pipe Network

8.Industrial Pipe Networks Such As Food, Chemical, Electronics, etc.



ASB has passed the ISO9001 quality management system and ISO1400 environmental management system in the same industry through standardized management, strict testing and excellent service. At the same time, the company strictly controls the quality, and the products have passed the certifications of EU CE, Germany SKZ and Russia, Ukraine, Poland and other different standards. Products are exported to more than 90 countries and regions around the world including Germany, Britain, Poland, Russia, Mexico, Argentina, the Middle East, Southeastern Asia and Africa.
