Insulation Tube Manufacturer Colorful / Clear PVC Pipe

Model NO.	SB-PVC
Material	PVC
Maximum Voltage	<10KV
Thermal Rating	105
Size	1.0mm-110mm
Working Temperature	-30-105
Certification No	E360625
Fire Resistance	VW-1
Standard	ISO9001-2008
Certifications	RoHS, Reach
Sample	Sample Supplied
Product Name	ISO9001-2008 Silicone High Temperature Insulation
Voltage	600V
Tensile Strength	Excellent
Type	Insulation Sleeve & Tube
Chemistry	Hybrid Insulation
Classification	Hybrid Insulation Materials
Certification	ISO9001, RoHS Reach
Brand	Sunbow
Transport Package	Carton
Specification	35*35*60cm
Trademark	SUNBOW
Origin	Shenzhen Guangdong China
HS Code	39173100
Production Capacity	600000m/Month

Insulation Tube Manufacturer Colorful / Clear Pvc Pipe

Product Description

1.Model Number
SB-PVC

2. Working Temperature

 -30C-105C

3. Structure

1)produced by superior and environmental- friendly polyvinyl colloidal particle, after drying
2)extruded to tubing when heated up and liquated
3)packing in rolls after cooling.



4. Application

RoHS Compliant Soft Flame Retardant PVC Tubing is widely used in
1)outside insulation protection of outgoing wires of electrical appliances
2)transformers, electrical motors or lighting equipment
3)electronic components, wire harness and etc.

5. Dimension


Size(MM)Wall thickness(MM)After recovery SB-300SB-600I.D. 0.80±0.10.25±0.050.40±0.05500 1.0±0.10.30±0.050.40±0.05500 1.5±0.10.33±0.050.45±0.05400 2.0±0.20.33±0.050.50±0.05400 2.5±0.20.35±0.050.50±0.05300 3.0±0.20.40±0.050.50±0.05300 3.5±0.20.45±0.050.50±0.05300 4.0±0.20.45±0.050.55±0.05300 4.5±0.30.45±0.050.55±0.05300 5.0±0.30.45±0.050.55±0.05300 6.0±0.30.45±0.050.55±0.05300 07.0±0.30.45±0.050.55±0.05150 8.0±0.350.45±0.050.55±0.05150 9.0±0.350.50±0.050.60±0.05150 10.0±0.350.55±0.100.65±0.10150 11.0±0.400.55±0.100.65±0.10150 12.0±0.400.55±0.100.65±0.10150 13.0±0.400.55±0.100.65±0.10150 14.0±0.400.55±0.100.65±0.10150 15.0±0.400.60±0.100.70±0.1050 16.0±0.400.60±0.100.70±0.1050 17.0±0.400.60±0.100.70±0.1050 18.0±0.400.60±0.100.70±0.1050 19.0±0.400.65±0.100.75±0.1050 20.0±0.500.65±0.100.75±0.1050 21.0±0.500.65±0.100.75±0.1050 22.0±0.500.70±0.100.80±0.1050 23.0±0.500.70±0.100.80±0.1050 24.0±0.500.75±0.100.85±0.1050 25.0±0.500.75±0.100.85±0.1050 26.0±0.500.85±0.100.85±0.1050




Insulation Tube Manufacturer Colorful / Clear Pvc Pipe

6. Our Services

1) 3~5 workdays of delivery

2) 2 years quality guarantee

3) prompt feedback

4) 24hrs on line service

7.Certification



8. About Sunbow

1) 10-year exporting experience

2) 15-year manufacturing experience

3) ISO9001:2008 approved

4) product certifications: CUL (E333178---UZIQ2 VW-1; E333177---UZFT2/8  200C  600V)

5) business partners:

Sanyo, Panasonic & Tiger, SEB, Philips, Black & Decker, Emerson & Conair, HOT, Midea
