PVC Braided Reinforced Hose - Flexible Garden Water Pipe for Industrial Use

Introduction

PVC garden hose is a flexible hose made from polyvinyl chloride (PVC) used for various purposes in the garden (Conveying water, gardening and general drainage). It is typically used to water plants, wash cars, and clean outdoor surfaces. PVC garden hoses are lightweight, durable, and resistant to kinks and tangles. They are also resistant to UV rays, chemicals, and extreme temperatures.

Feature and Detail

* Material: Made from polyvinyl chloride (PVC).

* Reinforcement: High tensile polyester fibre to increase strength and pressure resistance.

* Flexibility: PVC offers good flexibility, making it easy to maneuver around plants and obstacles.

* Durability: Resistant to UV rays, chemicals, and abrasion, making them suitable for outdoor use.

* Lightweight: Generally lighter than rubber hoses, making them easier to handle and move around.

* Kink Resistance: Designed to resist kinking under pressure, allowing for consistent water flow.

* Couplings: Typically fitted with brass or other metal couplings for connecting to faucets and accessories.

* Working Temperature Range: -10℃ to +65℃( 14℉ to +150℉ )

Specification

PVC Garden Hose Parameter

I.D.

Thickness

W.P.(Bar)

B.P.(Bar)

Length(m)

Weight
(kg/roll)

3/8''

10mm

2mm

7

21

100

9.8

1/2''

12mm

2mm

6

18

100

11.5

1/2''

12mm

2.5mm

7

21

100

12.3

1/2''

13mm

2.5mm

6

18

100

15.9

5/8''

15mm

2.5mm

7

21

100

17.9

5/8''

16mm

2mm

5

15

100

15.2

5/8''

16mm

2.5mm

6

18

100

18.9

3/4''

19mm

2.5mm

6

18

50

11

3/4''

19mm

3mm

7

21

50

13.95

1''

25mm

2.5mm

5

15

50

14.05

1''

25mm

3mm

6

18

50

17.15

Please enter the title here

Production Process
1. Raw Material Preparation: High-quality PVC resin, plasticizers, stabilizers, and colorants are carefully selected and weighed according to precise formulations. This ensures the hose meets standards for flexibility, durability, and weather resistance.
2. Mixing and Plasticizing: The raw materials are added to a high-speed mixer for thorough blending, creating a uniform dry blend. This mixture is then fed into an extruder, where it undergoes heating and shearing to become a molten PVC compound with consistent viscosity.
3. Extrusion Molding: The molten PVC is pushed through a specialized die under controlled pressure, forming the inner tube of the hose. Simultaneously, a reinforcement layer (such as polyester yarn or mesh) may be embedded during this stage to enhance strength and prevent kinking.
4. Cooling and Sizing: The newly formed hose is immediately passed through a cooling water tank, which rapidly solidifies the PVC and maintains the desired dimensions. Sizing tools ensure the hose has accurate diameter and wall thickness.
5. Surface Treatment: After cooling, the hose undergoes surface polishing or coating to improve smoothness, UV resistance, and resistance to abrasion. This step also enhances the hose's appearance and ease of handling.
6. Cutting and Inspection: The continuous hose is cut into standard lengths using precision cutting equipment. Each piece undergoes strict quality inspection, including checks for leaks, cracks, dimensional accuracy, and overall performance, to ensure only qualified products leave the factory.
Applications
PVC garden hoses are widely used by homeowners and gardeners for various outdoor watering needs.
* Gardening and Lawn Care: Watering plants, lawns, and gardens, as well as for general irrigation.
* Vehicle Washing: Effectively cleaning cars, motorcycles, and other vehicles.
* Outdoor Cleaning: Washing patios, decks, driveways, and other outdoor surfaces.
* Light Industrial Use: In some cases, PVC hoses can be used for low-pressure industrial applications where flexibility and ease of handling are important.
