Biaxial Oriented PVC-O Pipe Supplier

Model NO.	PVC-P
Type	Thermoplastic Pipe
Color	Color
Hollow	Solid
Shape	Round
Usage	Water Supply Pipe
Density	1.4G/Cm3
Transport Package	Plastic Bag
Specification	OD 110mm~600mm
Trademark	lida
Origin	China
HS Code	39172300
Production Capacity	65000tons Per Year

China PVC-O pipe manufacturer

Product introductions:
PVC-O, Chinese name of biaxial oriented PVC, is the latest evolution of PVC pipe form.  It is made of pipes by special orientation processing technology. The PVC-U pipe produced by extrusion method is axial and radial stretching, so that the PVC long chain molecules in the pipe are arranged in biaxial order, and a new type of PVC pipe with high strength, high toughness, high impact resistance and fatigue resistance is obtained.

Specification:

PVC-O pipe                                                            Standard:CJ/T 445-2014/ISO 16422:2006        class 400  C=1.6 OD mmThickness mmPressure MPaOD mmthickness mmPressure MPa 1102.21.02805.51.0 2.71.256.91.25 3.41.68.61.6 4.22.010.72.0 5.32.513.42.5 1252.51.03156.21.0 3.11.257.71.25 3.91.69.71.6 4.82.012.12.0 6.02.515.02.5 1402.81.03557.01.0 3.51.258.71.25 4.31.610.91.6 5.42.013.62.0 6.72.516.92.5 1603.21.04007.91.0 4.01.259.81.25 4.91.612.31.6 6.22.015.32.0 7.72.519.12.5 1803.61.04508.81.0 4.41.2511.01.25 5.51.613.81.6 6.92.017.22.0 8.62.521.52.5 2003.91.05009.81.0 4.91.2512.31.25 6.21.615.31.6 7.72.019.12.0 9.62.523.92.5 2254.41.056011.01.0 5.51.2513.71.25 6.91.617.21.6 8.62.021.42.0 10.82.526.72.5 2504.91.063012.31.0 6.21.2515.41.25 7.71.619.31.6 9.62.024.12.0 11.92.530.02.5

Production principle:

1. Tensile orientation mechanism of polymer materials.

The tensile orientation process of polymer materials is the process of molecules from disordered arrangement to ordered arrangement under the action of external forces under the temperature conditions between the glass transition temperature and the melting temperature (generally near the softening point).

1. Ratio and stretching rate.

Stretch orientation is the straightening and alignment of curly molecular chains in the direction of stretch.

1. Biaxial drawing of PVC-U pipe.

PVC is an amorphous amorphous plastic. Biaxial tensile orientation, through the biaxial tensile orientation, not only increases the axial strength of the pipe, but also increases the radial (that is, circumferential) strength of the pipe.

Characteristics:
1.Excellent elasticity.
2. Ultra high strength.
3.Convenient connectivity.
4. Excellent sanitary properties.
5.Excellent anti-cracking ability.
6.Unparalleled impact resistance.
7. Excellent water hammer resistance.
8. Good low temperature resistance brittleness.
9. Environmental protection and energy savingExecution standard:
This product is the main export product of our company, the products are exported to
the United Kingdom, Spain, Australia, Singapore, South Korea and other more than
ten countries.

R&D:
Our company has a number of independent laboratories and a high degree of automation of scientific research equipment. Every year, we invest a lot of money, introduce talents and technology, and have a strong scientific research force.

Application:
PVC-O pipe is mainly used in water supply pipeline, mine pipeline, trenchless laying and repairing pipeline, gas pipe network and other fields.  The use of PVC-O in drinking water pipes in some countries is gradually expanding as a substitute for PVC-U pipe.
