SDR26 SDR21 Extruded White PE PP Extruded Plastic Polyethylene Pipe

Model NO.	plastic pipe
Material	HDPE/PP
Kind	Thermoplastics Pipes
Water Absorption	0.1%~0.3%
Contraction Percentage	0.4%~1.4%
Tensile Strength	51~80MPa
Hardness	Hard Tube
Specifications	20mm-1200mm
Standard	Chemical 20539-92, GB/T13663.2-2018
Model No.	HDPE/PP Water Pipe
Transport Package	Standard Export Packing
Specification	custom
Trademark	Hebei Zeyi
Origin	China Hebei
HS Code	39172100



HDPE/PP pipe is a plastic pipe made of pipe grade specialized plastic HDPE/PP, necessary additives and oxidants, and formed through extrusion process. The HDPE/PP pipeline system has a 70 year history of use, and its processing, installation, and use are all very mature.

The plastic (HDPE/PP) pipeline system has good flexibility, corrosion resistance, and excellent impact resistance. The pipes and fittings can be connected by hot melt socket and butt joints to ensure the safety and reliability of the pipeline system and low construction costs. Widely used in fields such as water supply, mining, gas transmission, industry, and fire protection.

Production Standard: Chemical 20539-92, GB/T13663.2-2018


Material

100% PP /HDPE material

Outsite diameter

20mm-1200mm

Thickness

2mm-100mm

Pressure

0.4Mpa, 0.5Mpa,0.6Mpa, 0.8Mpa, 1.0Mpa,1.25MPa,1.6MPa,2.0MPa

Standard

Chemical 20539-92, GB/T13663.2-2018



PP PIPE


 Nominal outer diameter (mm)Pressure           level 0.4MPa0.5MPa0.6MPa0.8MPa       1.0MPa   SDR41SDR33SDR26SDR21SDR17 wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm) 20        2.5+0.40.14  25      2.50.172.8+0.40.20  30         0.27  32      2.80.253.0+0.60.38  40    2.10.232.80.313.4+0.60.58  50  2.00.282.60.363.40.474.2+0.60.89  632.00.362.30.413.30.584.30.755.2+0.71.26  752.00.432.70.573.90.815.11.106.2+0.91.82  902.00.523.20.824.71.206.11.517.5+1.02.70  1102.50.813.91.235.71.767.52.279.1+1.23.50  1252.81.024.41.576.52.278.51.9210.4+1.34.37  1403.21.325.02.007.32.859.53.6511.6+1.45.72  1603.61.705.72.608.33.8010.84.7313.3+1.67.25  1804.12.136.43.279.44.8012.26.0214.9+1.78.95  2004.52.627.14.0510.45.8013.57.4116.6+1.910.35  2185.13.287.94.9011.06.7014.48.6317.6+2.111.32  2255.13.387.95.0611.77.3515.29.3818.7+2.113.92  2505.64.108.35.9113.09.0517.011.6520.7+2.317.50  2806.45.229.97.9014.511.3018.914.5023.2+2.622.20  3157.16.5011.110.0016.314.3521.218.3026.1+2.928.10  3557.98.1112.512.6118.418.5023.923.9029.4+3.235.70  4009.110.5014.116.1020.723.2026.929.5033.2+3.6  45012.216.0015.820.5023.330.0030.538.00   50014.221.2017.625.0025.736.5033.947.20   56015.926.0019.732.0028.745.00     63017.833.0022.140.0032.758.00     The following large-diameter pipe specifications do not refer to the pressure rating in this gauge. Other thickness pipes of the same specification can be produced according to customer needs 7101530.501836.402040.3025    8001534.401841.202045.6025    9001538.801846.402051.4025    10002057.302571.203085.00     12002069.002585.8030102.50

HDPE pipe

 Nominal outer diameter (mm)Pressure           level 0.4MPa0.5MPa0.6MPa0.8MPa       1.0MPa  1.25MPa1.6MPa2.0MPa SDR41SDR33SDR26SDR21SDR17SDR13.6SDR11SDR9 wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm)Meter weight(m/kg)wall  thickness(mm) 20            2.30.135 2.30.135  25          2.30.174 2.30.174 3.00.215  32        2.30.228 2.40.236 3.00.283 3.60.332  40      2.30.290 2.40.300 3.00.362 3.70.437 4.50.517  50    2.30.367 2.40.380 3.00.461 3.70.558 4.60.677 5.60.806  63    2.50.493 3.00.589 3.80.732 4.70.895 5.81.076 7.11.285  75    2.90.686 3.60.840 4.51.031 5.61.264 6.81.507 8.41.812  90    3.50.993 4.1.203 5.41.493 6.71.819 8.22.178 10.12.615  110    4.21.454 5.31.804 6.62.217 8.12.685 10.03.242 12.33.891  125    4.81.888 6.02.322 7.42.837 9.23.470 11.44.203 14.05.033  140    5.42.378 6.72.917 8.33.555 10.34.337 12.75.245 15.76.319  160    6.23.113 7.73.816 9.54.652 11.85.678 14.66.884 17.98.362  180    6.93.896 8.64.794 10.75.897 13.37.198 16.48.841 20.110.581  200    7.74.821 9.65.948 11.97.272 14.78.846 18.210.912 22.413.080  225    8.66.055 10.87.533 13.49.222 16.611.437 20.513.813 25.218.570  250    9.67.517 11.99.213 14.811.314 18.414.070 22.717.021 27.920.383  280    10.79.396 13.411.629 16.614.478 20.617.669 25.421.322 31.325.615  3157.77.714 9.79.644 12.111.941 15.014.632 18.718.339 23.222.376 28.627.033 35.232.418  3558.79.843 10.912.221 13.615.108 16.918.912 21.123.328 26.128.382 32.234.293 39.741.198  4009.812.450 12.315.527 15.319.148 19.124.118 23.729.521 29.435.995 36.343.549 44.752.274  45011.015.732 13.819.592 17.224.690 21.530.495 26.737.416 33.145.630 40.955.189 50.366.170  50012.319.541 15.324.136 19.130.480 23.937.684 29.746.242 36.856.337 45.468.076 55.881.579  56013.724.367 17.230.986 21.438.201 26.747.193 33.257.903 41.270.661 50.885.340 62.5102.313  63015.430.852 19.339.107 24.148.461 30.059.615 37.473.350 46.389.336 57.2108.121 70.3129.516  71017.439.983 21.849.786 27.261.617 33.975.938 42.193.124 52.2113.528 64.5137.343 79.3164.631  80019.650.828 24.561.881 30.678.139 38.196.254 47.4118.083 58.8114.080 72.6174.295 89.3208.914  90022.064.216 27.679.973 34.498.754 42.9121.852 53.3149.419 66.2182.509 81.7220.633    100024.579.311 30.698.528 38.2121.919 47.7150.600 59.3184.703 72.5222.294 90.2270.848    120029.4114.965 36.7142.287 45.9176.229 57.2218.386 67.9255.054 88.2324.867

Typical Properties:
Light weight --Wear resistan,

Low water absorption,

Excellent impact resistance,

Excellent corrosion resistance,

Good chemical stability,

Non-toxic and tasteless.
