PE 100 HDPE PE PVC Pipe Hose
Detailed specification for PE 100 HDPE PE PVC Pipe Hose
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | 2 inch |
| Type | Thermoplastic Pipe |
| Color | Color |
| Hollow | Hollow |
| Shape | Round |
| Usage | Drainpipe, Water Supply Pipe, Threading Pipe, Agricultural Irrigation Pipe |
| Standards | GB/T 13663, ISO 4427, etc. |
| Working Temperature | -40ºC to 60ºC |
| Maximum Pressure-Bearing Capacity | 0.6MPa-2.5MPa |
| HDPE Density | ≥0.941 G/Cm³ |
| Tensile Strength | 81~130MPa |
| Contraction Percentage | 0.4%~1.4% |
| Water Absorption | 0.1%~0.3% |
| Production Process | Extrusion Molding |
| Transport Package | Container Transportation |
| Specification | Customized |
| Trademark | FUREX |
| Origin | China |
| HS Code | 4009210000 |
| Production Capacity | Extrusion Molding |
High-Density Polyethylene (HDPE) Hose
High-Density Polyethylene (HDPE) Hose is a plastic hose product crafted from high-density polyethylene material. It delivers outstanding performance: it resists corrosion effectively, stands up well to impacts, remains flexible, and lasts for many years. Widely used in municipal water supply/drainage, gas delivery, agricultural irrigation, and industrial fluid transport, it has become an ideal substitute for traditional metal hoses.
Specification
Parameter
Specification
Material
High-Density Polyethylene (HDPE), compliant with GB/T 13663, ISO 4427, etc.
Density
≥0.941 g/cm³
Working Pressure
PN6-PN25 (0.6MPa-2.5MPa)
Temperature Range
-40℃to 60℃(short-term up to 80℃)
Corrosion Resistance
Resistant to acids, alkalis, salts, and chemicals; no scaling or rusting.
Connection Methods
Butt fusion, electrofusion, flange connections, etc.
Service Life
Over 50 years (underground installation)
Color Options
Black (with UV-resistant carbon black), blue (water supply), yellow (gas), etc
Production Process
Raw Material Blending
High-quality HDPE pellets are combined with antioxidants and UV stabilizers to boost the final product's durability.
Extrusion Molding
The blended material is melted using single-screw or twin-screw extruders, then formed into the desired shape via precision-engineered dies.
Hose Sizing
Dimensional precision and consistent wall thickness are achieved through vacuum calibration or internal pressure calibration.
Marking
Specifications, pressure ratings, production dates, and traceability codes are printed onto the hoses using laser technology.
Quality Inspection
This stage covers visual inspections, wall thickness measurements, hydrostatic pressure tests, and melt flow index assessments.
Packaging & Storage
Hoses are cut to the required lengths, then wrapped in protective film or bundled together to ensure safe transportation.
Applications
1. Municipal Engineering
Water & Sewage Systems: Urban potable water and wastewater pipelines.
Stormwater Management: Drainage and rainwater harvesting networks.
2. Gas Distribution
Medium/low-pressure gas pipelines (compliant with GB 15558.1).
3. Agricultural Irrigation
Drip and sprinkler systems with excellent weather resistance for water conservation.
4. Industrial Use
Chemical fluid transport, slurry pipelines, cable protection conduits, etc.
5. Other Applications
Geothermal heat pump systems, landfill leachate collection, and more.
