HDPE Pipe for Water Supply High Density Polyethylene Gas Pipe (PE80/PE100)
Detailed specification for HDPE Pipe for Water Supply High Density Polyethylene Gas Pipe (PE80/PE100)
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | customized |
| Material | HDPE |
| Kind | Thermoplastics Pipes |
| Water Absorption | ＜0.01% |
| Contraction Percentage | ＜0.4% |
| Tensile Strength | 30~40MPa |
| Length | 5.8m, 9m, 11.8m or as Required |
| Thickness | 2.3-59.3mm |
| Standard | ISO4427, En, DIN, as, ASTM |
| Color | Black |
| Shape | Round |
| Elongation | More Than 350 |
| Hollow | Hollow |
| Longitudinal Reversion | Less Than 3 |
| Model | 16-1200mm |
| Transport Package | Customized |
| Specification | Customized |
| Trademark | FUREX |
| Origin | China |
Water HDPE Pipes
Water HDPE Pipes are a type of flexible plastic pipe used for water supply,gas supply and nuclear power.made from thermoplastic high density polyethylene, non-toxic,food grade polyethylene virgin material is used, they are safe for potable water transfer, high toughness and durability,suitable for high pressure pipelines,leak free joined by butt welding, HDPE pipe coils are available.
Specification
PE Pipe for Water Supply(PE100)
Nominal diameter dn(mm)
Nominal Wall Thickness(mm)
PN0.6
PN0.8
PN1.0
PN1.25
PN1.6
SDR26
SDR21
SDR17
SDR13.6
SDR11
20
-
-
-
-
2.3
25
-
-
-
2.3
2.3
32
-
-
2.3
2.4
3
40
-
2.3
2.4
3
3.7
50
2.3
2.4
3
3.7
4.6
63
2.4
3
3.8
4.7
5.8
75
2.9
3.6
4.5
5.6
6.8
90
3.5
4.3
5.4
6.7
8.2
110
4.2
5.3
6.6
8.1
10
125
4.8
6
7.4
9.2
11.4
140
5.4
6.7
8.3
10.3
12.7
160
6.2
7.7
9.5
11.8
14.6
180
6.9
8.6
10.7
13.3
16.4
200
7.7
9.6
11.9
14.7
18.2
225
8.6
10.8
13.4
16.6
20.5
250
9.6
11.9
14.8
18.4
22.7
280
10.7
13.4
16.6
20.6
25.4
315
12.1
15
18.7
23.2
28.6
355
13.6
16.9
21.1
26.1
32.2
400
15.3
19.1
23.7
29.4
36.3
450
17.2
21.5
26.7
33.1
40.9
500
19.1
23.9
29.7
36.8
45.4
560
21.4
26.7
33.2
41.2
50.8
630
24.1
30
37.4
46.3
57.2
710
27.2
33.9
42.1
52.2
63.6
800
30.6
38.1
47.4
58.8
72.7
900
34.4
42.9
53.3
66.2
81.8
1000
38.2
47.7
59.3
73.5
-
1200
46.2
57.1
70.6
-
-
Water HDPE Pipes Innovative Design
(1) Non-toxic, tasteless and sanitary
(2) High toughness
(3) Corrosion resistance, aging resistance
(4) Excellent resistance to rapid cracking
(5) Good resistance to scratches
(6) Easy to recycle
(7) Service life with 50 years
Technical Highlights
1) Material: PE100
2) Specification: DN20mm-DN1400mm
3) Length: 5.8m, 9m, 11.8m or as required
4) Thickness: 2.3-59.3mm
5) Standard: ISO4427, EN, DIN, AS, ASTM
6) Color: Black
7) Application: water supply and drain, irrigation, mining, drainage, dredging, gas
8) Feature: Corrosion resistance, No leakage, High toughness
9) Normal pressure: PN6-PN16
10) Connection: Hot melt, butt fusion, electro fusion
11) Life span: 50 Years Under Normal Conditions
12) Certificate: ISO4427, ISO9001, CE
13) working temperature: -40℃ to 60℃
Packing & Delivery
Applications:
(1) Urban area water-supply work system:
Large diameter HDPE pipe is healthy and non-toxic and more suitable for urban water supply main conduit and buried tube.
(2) Replace cement tube, iron pipe and steel tube, applicable for renovation project:
It does not need large area excavation, HDPE pipe can be widely used in old town of pipe network reconstruction.
(3) Industrial materials transmission pipe:
Chemical industry, chemical fiber, food,forestry, pharmacy light industry and paper-making, metallurgical and other industrial raw material conveying pipe.
(4) Landscaping water supply network:
As landscaping project needs lots of water supply pipes, HDPE pipe is the best choice for its toughness and low costs.
(5) Sewage discharge pipes:
HDPE pipe have unique corrosion resistance, can be used as industrial wastewater and sewage discharged pipe.
(6) Ore and mud transfers:
HDPE pipe has high resistance to stress and wear resistance, can be widely applied in conveying ore, coal ash and river bait-casting mud.
(7) Agricultural irrigation pipe:
HDPE pipe has the merits of great flow and good impact resistance,it is the ideal tool for agricultural irrigation.
