Advanced Extrusion System for Large Diameter Plastic Pipes

Model NO.	ZX-250I
Screw No.	Single-screw
Automation	Automatic
Computerized	Computerized
Certification	ISO9001:2008
Customized	Customized
Condition	New
After-sales Service	One Year
Dimension(L*W*H)	25m*2.5m*3.5m
Control Mode	PLC Control
Weight	10t
Guaranteed Time	12 Months
Pipe Range	20-1600mm
Extruder Type	High Speed Single Screw Extruder
Pipe Type	Spiral Corrugated Pipe
Application	Drainage Pipe
Transport Package	Shrink Film Wrapped or Wooden Cases
Specification	Customized
Trademark	Zhaoxing
Origin	China
HS Code	8477209000

1. GENERAL DEscriptION

Large Diameter Plastic HDPE/PP Spiral Wound/Winding Pipe Production Line  is a kind of new generation high performance plastic spiral pipe line for large diameter buried drain pipe according to Corrugate pipe production technology; it can produce pipe size from Ø200~Ø2000mm which is widely used in fields of civil water drain, wastewater drain. the pipe could also be made by the recycled polyethylene material. These properties make it superior advantages compared to other kinds of drainpipe.

Our designed and manufactured PE/PP Spiral Corrugated Pipe Extrusion Machine includes two parts: The first part is PE Pipe Production Line. The function of it is to extrude PE/PP profiled T belt; the second part is Forming Machine, of which the function is to produce qualified HDPE winding pipe.
Introduction of PE/PP Spiral Corrugated Pipe:
PE/PP large diameter hollow wall winding pipes have been recognized as a substitute for cement pipes and cast iron pipes since it possesses such particular advantages as follows:
1) Light weight-per-meter
2) Belling link, tight cementation
3) Pressure against, high strength
4) Anti-frozen and long service life (50 years)
5) Convenient constructionTechnical Specification of our PE/PP Spiral Corrugated Pipe Extrusion Machine:

ModelDiameter range
(mm)ExtruderMax. capacity
(kg/h)Max. haul speed
(m/min)Extruder Motor power
(kw) ZX-63I20-63SJ65/332201255 ZX-110I20-110SJ65/332201255 ZX-160I50-160SJ75/3340010110 ZX-250I90-250SJ75/334006110 ZX-450I160-450SJ90/335004160 ZX-800I500-800SJ120/338502315 ZX-630I315-630SJ120/338502315 ZX-800I500-800SJ150/331,1001400 ZX-1200I710-1200SJ120/331,3500.7315 SJ90/33160 ZX-1600I1000-1600SJ150/331,7000.4400 SJ90/33160

2. DETAILED FEATURES OF OUR EXTRUSION LINE

1) The investment is lower and the automatic control system is easy for operation and maintenance.
2) Adopt the one-time hot-melt forming technology for inner and outer layer.
3) The inner PE belt is Composited with the U-type pipe in melting condition. Moreover, they will never be delaminated after spraying cooling forming; it has a good adhesion effect.
4). It adopts easy-to-use and fully automatic button control syetem. In addition, PLC control is also selective if customers need.
5). It adopts Electromagnetic heating system, which can save 40% to 50% electric power.
6). All Electric Part (breaker/motor/Inverter) is Siemens/Schneider/Omron.
7). Production speed is 1-10 meters per minute.
8). Maximum pipe size reach to 2000mm.
