Double Lumen of TPU Plastic Catheter for Surgical Wound Edge Protector Cover

Model NO.	BV-17283
Certification	CE, FDA, ISO13485
Ethylene Oxide Sterilization	Ethylene Oxide Sterilization
Application	Hospital
Group	All
Logo Printing	With Logo Printing
Color	Biue/White
Transport Package	PE Bag/Master Carton/ Pellet
Specification	design by customer
Trademark	Bova
Origin	Suzhou China
HS Code	9018909000
Production Capacity	50000/Week

Double Lumen of TPU Plastic Catheter for Surgical Wound Edge Protector Cover

BOVA PROVIDES CUSTOM-MADE COMPonENTS FOR MEDICAL DEBVICES

Major Products:

Medical Grade PA/PEBAX tube, HDPE tube, LDPE tube, PU/TPU/TPE tube, PVC tube, PP/PE tube, PC tube, PS tube, ABS tube, etc.
Material Style: PU.

Product features:
Made of non-toxic medical grade PU or silicone.
It provide 360degree protection for surgical incision and 360degree pulling without hurting
Reducing the infection of surgical incision.
Minimize the surgical incision and maximize the exposure.
It provides optimal vision for surgical operation.

Disposable wound edge protector
Features of protector and retractor of  surgical incision  below:

1.made of high-quality nontoxic medical-grade PU

2.it provide 360°protection for surgical cuts and 360°pulling without   hurting

3.reducing the infection of surgical cuts

4.minimize the surgical cuts and maximize the explosion

5.it provides best vision for surgical operation

  Material Name TPU( polyurethane) Characteristics of TPU Hi-transparency, Excellent water resistance property; prefect biological compatibility, Non- cytotoxicity for human body, No irritation for human skin, no irritability for human; anti-low temperature, TPU material can still keep softly, elasticity and other physical characteristics under -35ºC;
Good chemical resistance,and anti-fungal.
The range of TPU solidity: 60A-75D Other characteristics
  good flexible &soft. Anti-wear, non-toxic, the products meet ROHS standard request.usually uses epoxyethane and gamma ray to sterilization for TPU products.
 Size of PP tube Outer Diameter: 0.8mm~11.00mm
Thickness Wall: 0.6mm~1.0mm
Deviation: ±0.02mm~±0.15mm Alternative Material Intervention treatment;analysis instrument;Automotive field. Extra value Service Assignable of the Tube color and size. Application of range The pneumatic connecting tube for medical monitoring area,the protecting tube for Automotive components.

Material Characteristic

 HDPELDPEPA12PEBAXTPUPP Density0.960.931.151.011.2-1.250.88 Rigidity60D-65D48D-53D68D-70D23D-72D60A-75D60-69D Max. Operation temperature54ºC54ºC80ºC80ºC80~100ºC80~100ºC Min. Operation temperature-40ºC-40ºC-40ºC-20ºC-35ºC-20ºC TenacityCommonlygoodcommonlycommonlyExcellentcommonly ColorMilk WhiteTranslucentTranslucentTransparentTransparentTranslucent Reprocessing performance CharacteristicsCommonlyEasyEasyEasyEasyCommonly Chemical ResistanceGoodGoodGoodGoodCommonlyGood InsulationGoodGoodGoodGoodGoodGood  BiocompatibilityGoodGoodExcellentExcellentExcellentGood Medical Grade AttestationYesyesyesyesyesyes



Our Company:

Kunshan Bova Plastic Co., Ltd.Was established in 2008, now located at NO.578 Jujin Road, Zhangpu Town, Kunshan City, Jiangsu Province.The company mainly provides precision extrusion catheter, secondary operation for catheter and catheter custom-made service.The company produces various materials such as TPU,PE,PP,PVC,Pebax,PA,PEEK,PSU,PPSU,PC,EVA,TPE,ABS,PCL,PLA,PTFE,FEP,Silica and various shapes of extruded pipes, such as single-lumen tubes, multi-row tubes, multi-color co-extrusion tubes, multi-layer coated tubes, X-ray development tubes, Thin-walled tube, metal-coated plastic tube, microcatheter, etc., The company has been committed to the production of plastic precision extrusion and catheter product research and development since its establishment.At present, the diameter deviation of extruded pipe can be controlled at ±0.02 mm, and the wall thickness can reach 0.06 mm.The company owns standard 100000 level clean room for production and passed ISO9001 quality system certification in 2016 and ISO13485 quality system certification in 2019.



Delivery:

For product in stock, we will ship within 3-5 days.
For OEM product, please inquire.
Transport Package:Double layer PE bags→Carton→Pallet
Payment Item:T/T ,50% Deposit, 50% Balance Before Shipment.
