Round Head Yttria Stabilized Zro2 Pipe Zirconium Oxide Ceramic Sleeve
Detailed specification for Round Head Yttria Stabilized Zro2 Pipe Zirconium Oxide Ceramic Sleeve
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | G-E348 |
| Length | Customized |
| Temperature Resistance | 1500℃ |
| Shape | Tubular, Pipe, Tubing, Sleeve, Bush |
| Use | Thermocouples or Polycrystalline Furnace, Ingot F |
| Temperature | 1000c |
| Application 2 | Precision Shafts and Axles in High Wear |
| Material | Zirconia Ceramic |
| Purity | Zro2 + Hfo2 86.0% Y2o3 13.5% |
| Type | Ceramic Tubes |
| Transport Package | Plywood Case |
| Specification | CUSTOMIZED |
| Trademark | Yunnuo |
| Origin | China |
| HS Code | 8547100000 |
YSZ Zirconia ceramic protection tube:
Material
Zirconia (ZrO2 + HfO2 86.0% Y2O3 13.5%)
Shape
one round closed end
Process
isostatic pressing
Structure
Fully stable zirconia
Temperature resistance
1800 ~ 2300 ºC
Applicable places
polycrystalline furnace, ingot furnace
Item no
Size in OD x ID x Length in mm
Remarks
ZT-001
6x3x250
One end closed
ZT-002
6x4x120
One end closed
ZT-003
8x5x250
One end closed
ZT-004
8x5x300
One end closed
ZT-005
8x5x350
One end closed
ZT-006
9x5x550
One end closed
ZT-007
9.5x6x400
One end closed
ZT-008
10x6x200
With thread
ZT-009
10x6x300
One end closed
ZT-010
10x6x500
One end closed
ZT-011
10x6x600
One end closed
ZT-012
11.1x8x365
One end closed
ZT-013
12x8x300
One end closed
ZT-014
12.7x9.53x230
Both ends open
ZT-015
12.7x9.53x327
One end closed
ZT-016
12.7x9.5x365
One end closed
ZT-017
12.7x9.5x370
One end closed
ZT-018
12.7x9.53x375
One end closed
ZT-019
12.7x9.53x380
One end closed
ZT-020
12.7x9.53x385
One end closed
ZT-021
12.7x9.53x390
One end closed
ZT-022
12.7x9.53x395
One end closed
ZT-023
12.7x9.53x397
One end closed
ZT-024
12.7x9.5x400
One end closed
ZT-025
12.7x9.53x415
One end closed
ZT-026
12.7x9.53x430
One end closed
ZT-027
12.7x9.53x435
One end closed
ZT-028
13x8.5x700
One end closed
ZT-023
12.7x9.53x397
One end closed
ZT-024
12.7x9.5x400
One end closed
ZT-025
12.7x9.53x415
One end closed
ZT-026
12.7x9.53x430
One end closed
ZT-027
12.7x9.53x435
One end closed
ZT-028
13x8.5x700
One end closed
