MGO Magnesia Partially Stabilized Zro2 Zirconia (Mg-PSZ) Ceramic Pipe Rod
Detailed specification for MGO Magnesia Partially Stabilized Zro2 Zirconia (Mg-PSZ) Ceramic Pipe Rod
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | YNZ006 |
| Purity | 95% |
| Type | Ceramic Part |
| Volume | 10ml, 20ml, 30ml, 50ml, 100ml, 150ml, 200-2000ml |
| Working Temperature | 1000c-2000c |
| Accessory | with Lid or Cover |
| Material 2 | Magnesia Stabilized Zirconia, Mg Psz |
| Synonyms 1 | MGO Stabilized Zro2, Mg-Psz |
| Synonyms 2 | Zirconium Magnesium Oxide; Magnesium Zirconate; |
| Synonyms 3 | Yellow Magnesia Partially Stabilized Zirconia;Msz |
| Transport Package | Plywood Cases or Carton |
| Specification | 5ml-1000ml |
| Trademark | Yunnuo |
| Origin | China |
| HS Code | 8547100000 |
Zirconia ceramics
Advantages:
1. High strength and high hardness;
2. Good abrasion resistance;
3. High toughness;
4. Low friction coefficient;
5. Good corrosion resistance;
6. Low thermal conductivity;
7. The modulus of elasticity and coefficient of thermal expansion are close to metals.
Details:
1.Zirconia ceramics have the advantages of high hardness, good wear resistance, high toughness, low
coefficient of friction, and good corrosion resistance. They are widely used in mechanical seals, ball milling media, cutting tools, ceramic bearings,automotive engine parts, etc.
2.The wear resistance of zirconia ceramics is 15 times that of alumina ceramics. The friction coefficient of
zirconia ceramics is only 1/2 of that of alumina ceramics, while the friction coefficient of alumina ceramics is
very low.
3.The density of zirconia ceramics is higher than that of alumina ceramics. The density of alumina ceramics is 3.5. The density of zirconia ceramics is 6. The texture is more delicate. After grinding, the surface finish is higher than
9. It is mirror-like,extremely smooth, and has a smaller coefficient of friction.
4.In addition, the toughness of zirconia ceramics is excellent, which overcomes the inherent brittleness of the
ceramics, has higher wear resistance, and greatly extends the service life of the product.
Applications of zirconia ceramic
* Structural ceramics:
Mainly include: Y-TZP grinding ball, nozzle, ball valve ball seat, fiber optic sleeve, drawing die and cutting tool,
wear-resistant cutter, case and strap, bracelet and pendant, ball bearing, etc.
* Functional ceramics:
Used as induction heating tubes, refractory materials, and heating elements. Used in fields such as oxygen sensors, solid oxide
fuel cells, and high-temperature heating elements.
In addition, zirconia is widely used in thermal barrier coatings, catalyst carriers, medical, health care, refractory materials,
textiles and other fields.
Material data:
9 mol% magnesia partially stabilized zirconia (Mg-PSZ)
Item
Unit
Value
Color
Yellow
Density
g/cm3
5.7
Bending strength
MPa
500
Compressive strength
MPa
2,500
Elastic Modulus
GPa
250
Fracture toughness
MPam1/2
6~7
Weber coefficient
M
12
Vickers hardness
HV0.5
1,100
Linear expansion coefficient
10-6K-1
10
Thermal conductivity
W/mK
3
Resistance to thermal shock (water cooling)
TC
450
Maximum use temperature
C
2,100
Volume resistance, 20 ºC
Ωcm
>1014
Dielectric strength
V/m
13×105
