Pre-Insulated Copper Pipe Green Infrastructure Temperature Resistance Rubber Insulated Copper Pipe
Detailed specification for Pre-Insulated Copper Pipe Green Infrastructure Temperature Resistance Rubber Insulated Copper Pipe
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | Rubber Copper Pipe |
| ventilation mode | mechanical ventilation |
| Certification | TUV, ISO9001, ROHS |
| Material | Rubber/Copper |
| Thickness | Copper:0.6-1mm/Insulation:8-12mm |
| Length | 3/5/10/15/20/30/50/Customized |
| Package | Carton Box |
| Delivery | 15-30days |
| Transport Package | Carton Box |
| Specification | 1/8" 1/4" 3/8" 1/2" 5/8" 3/4" 7/8" |
| Trademark | Jiahao |
| Origin | Jiangsu |
| HS Code | 7411290000 |
• Low thermal conductivity: not exceeding 0.034W/m · k at 0 °C, with excellent insulation performance.
• Completely closed cell structure: The insulation effect is long-lasting and good, which can effectively reduce heat loss.
• Strong resistance to water vapor penetration: Moisture resistance μ ≥ $000, forming a "built-in" waterproof layer.
• Good fire resistance: oxygen index above 32, not easy to burn, safe to use.
• Strong corrosion resistance: It can effeetively resist the erosion of various chemical substances and extend the service life of pipelines.
• Environmentally friendly and non-toxic: It does not contain fluorinated materials such as CFC, HFC, or HCFCs, does not contain formaldehyde, dust, or fibers, and has no pollution to the environment.
SPECIFICATION
SIZE OF COPPER TUBE
COPPER TUBE THINKNESS
1/4" WHITE PE
6.35MM
0.37/0.38/0.55/0.62/0.65/0.7/0.72/0.8MM
3/8" WHITE PE
9.52MM
0.37/0.38/0.55/0.65/0.68/0.72/0.75MM
1/2" WHITE PE
12.7MM
0.72/0.74/0.75MM
5/8" WHITE PE
15.88MM
0.85/0.9/1MM
3/4" WHITE PE
19.05MM
0.85/0.93MM
7/8" WHITE PE
22.22MM
1.1/0.95MM
SIZE OF INSULATION TUBE(INNER DIAMETER)
WALL THINKNESS OF INSULATION TUBE
LENGTH (M)
8MM
8MM/9MM/10MM/13MM/19MM/25.4MM
3/4/5/6/7.6/8/10/15/25/30/50
10MM
8MM/9MM/10MM/13MM/19MM/25.4MM
3/4/5/6/7.6/8/10/15/25/30/50
13MM
8MM/9MM/10MM/13MM/19MM/25.4MM
3/4/5/6/7.6/8/10/15/25/30/50
16-17MM
8MM/9MM/10MM/13MM/19MM/25.4MM
3/4/5/6/7.6/8/10/15/25/30/50
20-22MM
8MM/9MM/10MM/13MM/19MM/25.4MM
10/15/25/50
