Suitable for Underground or Above-Ground Installation FRP Pipes for Environmentay Irrigation Water P
Detailed specification for Suitable for Underground or Above-Ground Installation FRP Pipes for Environmentay Irrigation Water P
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | wish |
| Thickness | 4.6mm-28.8mm |
| Usage | Environmental Protection, Industral, Household |
| Product Categories | FRP Pipe |
| Molding Method | Wind |
| Material | Fiberglass |
| Fiber Type | GFRP |
| Type | Polyester FRP |
| Product Name | FRP Pipes |
| Full Name | Glass Fiber Reinforced Plastics Mortar Pipes |
| Application1 | Water Conservancy Project |
| Application2 | Power Industry |
| Application3 | Municipal Water Supply and Drainage |
| Application4 | Chemical Enterprises |
| Advantage1 | Corrosion Resistance |
| Advantage2 | Aging Resistance |
| Advantage3 | Flexible Design |
| Advantage4 | Low Thermal Conductivity |
| Feature1 | Fluid Transport |
| Feature2 | Corrosion Protection |
| Feature3 | Electrical Insulation |
| Feature4 | Beautify The Environment |
| Customized | OEM / ODM |
| Transport Package | Container |
| Specification | DN50mm-DN4000mm |
| Trademark | HEBEI WISH |
| Origin | China, Hebei |
| HS Code | 39174000 |
Product Description
Fiberglass reinforced plastic pipes are pipes made of fiberglass reinforced materials and resin matrix, which have many excellent characteristics. The production process generally includes the following steps:Firstly, immerse the glass fiber in the resin, and through winding, extrusion, or other molding processes, fully combine the glass fiber with the resin to form a pipeline body with a certain strength and shape.
Then, through a curing process, the resin undergoes a chemical reaction at a certain temperature and time to solidify and form, thereby obtaining fiberglass pipes with excellent performance.
Strictly control material quality and process parameters during the production process to ensure stable product quality.
It has excellent corrosion resistance and can withstand the erosion of various corrosive media, making it suitable for fields such as chemical, petroleum, and sewage treatment.
Meanwhile, fiberglass pipes also have good wear resistance and are suitable for conveying materials such as particles and powders.
In addition, it also has the characteristics of lightweight and high strength, good insulation, low thermal conductivity, smooth inner wall, and low water flow resistance, making it easy to install and low maintenance cost.
Fiberglass reinforced plastic pipes are widely used in industries such as chemical, petroleum, power, metallurgy, papermaking, urban water supply and drainage, providing reliable solutions for fluid transportation in various fields.
Detailed Photos
specifications
application
Production process
Continuous winding:
1. Complex equipment, high price, high requirements, and poor flexibility
2. Large investment and high cost
3. High degree of automation, full process monitoring
4. Fewer operators and fewer human factors
5. The industry threshold is high, there are few manufacturers,
and it is relatively standardized
6. High product quality, uniform, stable, and reliable
7. High production efficiency
8. Good operating environment
9. High material utilization rate
10. Convenient inspection and maintenance
11. Unlimited length
12. sleeve connection with good hydraulic performance
Fixed length winding:
1. Simple equipment, low price, low requirements, convenient and flexible
2. Small investment and low cost
3. Limited degree of automation
4. There are many operators and human factors involved
5. Low industry threshold, multiple manufacturers, and uneven quality
6. Poor product stability and uniformity
7. Low production efficiency
8. Poor operating environment
9. Low material utilization rate
10. High cost of inspection and maintenance
11. Length limited by mold
12 socket connections affect hydraulic performance
Advantage:
Excellent water resistance, corrosion resistance, temperature resistance, heat and cold resistance, good wear resistance, excellent insulation performance, no toxicity, no secondary pollution, small specific gravity, light weight, few interfaces, high installation efficiency, good mechanical performance, excellent insulation performance, excellent hydraulic performance, energy-saving, low thermal expansion coefficient, flexible design, strong product adaptability, long service life, safe and reliable operation and maintenance costs
Packaging & Shipping
Company Introduction
Hebei Weishi New Materials Co., Ltd. was established in 2023. It is a comprehensive enterprise focusing on the design, research and development, manufacturing, sales and after-sales service of new material products. The company is located 1,000 meters south of the new campus of Hengshui University, on the shore of Hengshui At the junction of Huxin District and Zaoqiang, Hengshui Innovation Port.
The company is mainly engaged in the composite materials and wire mesh industries. Its products include: composite materials - FRP pipes, FRP storage tanks, FRP integrated pump stations, FRP gratings, FRP dissolved oxygen cones, FRP flower pots/flower boxes; wire mesh types - Filter mesh, welded mesh, window screen, chain link fence, steel grating, punched mesh, barbed wire, guardrail; serving the fields of building materials, municipal administration, roads, water conservancy, chemical industry, electric power and other fields.
Our company has a high-quality management and technical team. The team members have rich industry experience and professional knowledge, with special emphasis on product research and development and technological innovation capabilities. We have advanced production equipment and professional technology, and accept OEM, ODM, OBM, etc. A variety of cooperation methods can meet the different needs of customers.
Weishi New Materials adheres to the concept of "weishinnovation, quality first", constantly promotes the development and application of composite material technology, and provides customers with high-quality products and solutions. We are committed to becoming a leader in the field of composite materials, providing customers with high-quality products and services, creating development opportunities for employees, and contributing to society.
Weishi New Materials Social Responsibility:
Environmental protection measures: The company will actively take environmental protection measures to reduce pollution emissions during the production process and protect the environment.
Charity: The company will actively participate in charity and provide help to disadvantaged groups in society.
Employee welfare: The company will pay attention to the welfare and rights of employees and provide a good working environment, vocational training and development opportunities.
Our factory:
Our team:
Inspection equipment:
Customer visits:
