High Temperature Resistant Alumina Ceramic Tile Lining Pipe in Chemical Plant

Certification	ISO, BSI, CE
Material	Alumina Ceramic Pipe
Feature	Wear Resistant
Corrosion Rate	0.001-0.01
Item Name	Alumina Cermic Tile for Lining Pipe
Size	150X53/49.38X13mm, 150X53/49X25mm, 150X50/46X25mm
Shape	Trapezoid
Applications	Wear Protection
Installation	Bonded by Glue
Industry	Steel Plant, Power Plant, Refinery, etc
Facilities	Chute, Hopper, Stacker, Pipe, Bunker
Quality	Similar to Cumi
Delivery	Store Available
Transport Package	Box+Pallet
Specification	92% Alumina Series & 95% Alumina Series
Trademark	Chemshun
Origin	P. R. China
HS Code	69091200
Production Capacity	5000tons/Year

High Temperature Resistant Alumina Ceramic Tile Lining Pipe in Chemical Plant

Short description :
Chemshun ceramics produce ceramic lined pipe equipment and on site installation service for convoying system

Detailed description:
In aggressive industrial applications, conveying pipeline often suffer from serious damage by mechanical attack, chemical attack, corrosion, or by a combination of these three modes. To achieve both technical and economical wear protection , the best solution for long life and economical abrasion protection is alumina ceramic lined pipe. Chemshun ceramics as 15 years abrasion resistant ceramics manufacturer , we can assist you in technical analysis of wear damage conveying pipeline and produce integrated ceramic lined pipe equipment according to customer's industrial environment. Chemshun also offer onsite installation service providing skilled technicians and examination.

Appearance:


Product Description

Product NameAlumina Ceramic Tile for Lining Pipe Size150x53/49.38x13mm, 150x53/49x25mm,150x50/46x25mm,100x35/32x13mm DescriptionChemshun Alumina Ceramic Tile for Lining Pipe is also called Alumina Ceramic Pipe Tile.
It is used with advantage of the trapezoidal-shape and the benefit feature of the alumina
Ceramic in lining steel pipe to avoid corrosion and abrasion. And then reduce the maintenance
cost and prolong the use life of the pipes. Feature1.High purity;
2.High hardness;
3.Simple shape Benefit1.Excellent anti-resistant and corrosion resistance;
2.Excellent anti-impact;
3.Easy to pack and installation for using due to the simple shape and this could reduce
the time cost;
4.Its abrasion is 266 times than that of manganese, 171.5 times to high chrome cast iron. Application1.Used to be line in steel pipe Related IndustrySteel plant, power plant, refinery factory, cement plant, mining industry, port industry,etc. Facilities for liningChute, hopper, bunker, stacker, Belt conveyor, Coal feeder, Distributor, Pipe and Elbow, Burner, Valve

Specification

TechnicalUnit92AL95AL Alumina%9295 Densityg/cc3.603.68 Flexural StrenghtMpa275300 Rock well hardnessR45N7578 Vickers Hardness (HV10)Kg/mm210501120 Fracture ToughnessMpa.m1/23-44-5 Thermal Expansion  Coefficient(25-1000ºC)1X10-6/ºC8.08.1 Max. Use Temp.ºC12501250

Company Information

Company TypeAudited Manufacturer by SGS FoundedSince 2002, Specializing in producing and developing wear resistant alumina ceramics Capacity5000tons per year TeamProfessional service team to provide good services from design, sale, delivery,export and
after sale in all processes. Quality Control
Strict quality control, set up Q.C.to inspect the semi-finished product and finished product
in separately ;

Advance technology control the passing rate above 95% to down the cost in effectively
and the price is more better.

Services for Customer

Technology Support1.Provide professional technology advisory service to customer;
2..Design wear solution as per customer's requirements;
3.Provide the test reports to customer;
4.Welcome to plant inspection,technological exchanges and cooperation face to face. Quality1.Take care of every product of any customer's order no matter what the quantity and
2. the order amount;
3.Check the quality in all production processes;
4.Follow up the quality after sale. Delivery1.Promise timely delivery;
2. Advance or adjust the production schedule in sufficiently elastic to approach to the
customer's requirement Price1.Provide competitive price with best quality to customer;
2.Special discounts are available for large quantity orders without down the quality.

Service:
Any requirment about chemshun Alumina Ceramic Square Mosaic Tile , Wear Resistant Ceramic Pipe Tile , Wear Ceramic Liner  ,wear resistant ceramic, alumina ceramic rubber wear plate ,Wear Resistant Rubber Ceramic Panels, please feel free contact us and chemshun we'll afford you the most suitable product and best service.

Export:
Our products have been exported to many countries: Australia, Chile, USA, Russia, UK, Indonesia, etc., good quality have be approved by our
clients.
