Product Overview
Detailed specification for Fcd Dm300-500-12 Articulated Pipe (POWER CABLE SHELL PROTECTOR)
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | 300-500-12 |
| Joint Type | Articulated |
| Section Shape | Round |
| Certification | ISO2531, EN545, ISO 1083/Js/400-15/S |
| Shape | Round |
| Customized | Customized |
| Quality Control | 100% Inspection and ISO9001 Quality Control System |
| Transport Package | Wood Pallet; as Per Your Requirement |
| Specification | AC030-400MM |
| Trademark | Vortex |
| Origin | China |
| HS Code | 73071100 |
| Production Capacity | 800tons/Month |
Ductile cast iron pipe, including Articulated Pipe for submarine cable AC/Dm Series ductile iron Articulated Protection Pipe
Product Description
The cable bundle will be protected in shallow waters, by means of using ductile cast iron articulated pipes, where burying is not possible. Total order package covers the design and supply of articulated pipes and a fully compatible repair kit for possible remedial works in the future.
Our protection systems are well tested & proven products providing; strong & reliable locking mechanism, bend restriction, impact strength and a straight forward assembly on the board of the vessel.
| size | inside mm | thickness | length mm | cable outside mm | note |
| AC040-500 | 40 | 9 | 500 | 35 | vortex |
| AC055-500 | 55 | 9 | 500 | 47 | vortex |
| AC076-500 | 76 | 9 | 500 | 66 | vortex |
| ac100-500 | 100 | 9 | 500 | 88 | vortex |
| ac120-500 | 120 | 9 | 500 | 108 | vortex |
| ac127-500 | 127 | 10 | 500 | 115 | vortex |
| ac140-500 | 140 | 10 | 500 | 127 | vortex |
| ac160-455 | 160 | 10 | 455 | 145 | vortex |
| ac180-500 | 180 | 10 | 500 | 160 | vortex |
| ac200-440 | 200 | 10 | 440 | 180 | vortex |
| ac210-500 | 210 | 10 | 500 | 192 | vortex |
| ac230-500 | 230 | 10 | 500 | 210 | vortex |
| ac260-500 | 260 | 10 | 500 | 240 | vortex |
| ac280-500 | 280 | 10 | 500 | 260 | vortex |
| Any size as you required |
| size | minimun internal diameter mm | thickness mm | effective install length mm | for cable mm |
| dm050-500 | 50 | 9 | 500 | 40 |
| dm070-500 | 70 | 9 | 500 | 60 |
| dm080-500 | 80 | 9 | 500 | 70 |
| dm100-500 | 100 | 10 | 500 | 88 |
| dm120-500 | 120 | 10 | 500 | 108 |
| dm130-500 | 130 | 10 | 500 | 118 |
| dm150-500 | 150 | 10 | 500 | 138 |
| dm160-500 | 160 | 10 | 500 | 140 |
| dm180-500 | 180 | 10 | 500 | 160 |
| dm200-500 | 200 | 12 | 500 | 180 |
| dm250-500 | 250 | 12 | 500 | 220 |
| dm280-500 | 280 | 12 | 500 | 250 |
| dm300-500 | 300 | 12 | 500 | 270 |
| dm320-500 | 320 | 12 | 500 | 280 |
| dm360-500 | 360 | 12 | 500 | 320 |
| dm375-500 | 375 | 12 | 500 | 330 |
| dm400-500 | 400 | 12 | 500 | 360 |
| Any size as you required |
Packaging & Shipping shipped by container,packed in pallets,the size is 110*110*110
Our Services goods quanlity,good service,and service after sale
Primary ProductFcd Dm300-500-12 Articulated Pipe (POWER CABLE SHELL PROTECTOR)
Contact PersonMr.GaryWong
Minimum Order1 Piece
PaymentsLC, T/T, PayPal, Western Union
DeliveryContact the supplier about freight and estimated delivery time.
OriginLancun East Industry Park, Qingdao, Shandong, China
PackingCarton Box+Plastic Bag
Inspection
SamplesProvide Samples
