DN100 Hygienic Performance Pipe with Advanced Mpp Technology for Durability

Product Parameters

TNon-excavated modified polypropylene(MPP) electrical protection pipe is a new type of composite pipe manufactured by using modified polypropylene as the main raw material and using special formulas and processing techniques. It has a series of advantages such as high strength, high temperature resistance, easy cable insertion, convenient construction and cost savings.  Non-excavation construction technology has no pollution to the environment, no impact on traffic, little damage to the underlying structure, safe and reliable construction, short construction time, low construction cost, guaranteed reliability, safety, reduced failure rate of the network, and significant social and economic benefits. At the same time, the city appearance environment is greatly improved, and it is suitable for the protection of the excavation field of buried high-voltage and ultra-high-voltage power cable bushings.

Specification

1,Raw materials:Polyolefin;

2,Grade: high-class products;

3,Standard: international standard;

4,Certification: ISO9001, ISO14001,ISO45001;

5,The pipe can be used in urban power grid construction and transformatiom;

6,Municipal Improvement Project;

7, Civil Aviation Airport construction Project;

8, Industry Zone and Residential area construction;

9, Transportation engineering construction;

10, Lamp cables' installation;

11, As protective pipe network, in telecommunication and cable TV signal area.

Technical Specifications

(Custom configurations available upon request.)

SIZE

O.D

Thickness

Length

Φ110

110mm

5mm

6m,9m,13m

Φ160

160mm

8mm

6m,9m,13m

Φ180

180mm

12mm

6m,9m,13m

Φ200

200mm

13mm

6m,9m,13m

Φ225

225mm

15mm

6m,9m,13m

Φ250

250mm

15mm

6m,9m,13m

After Sales Service

Standard Warranty: One Year
