Porous Alumina Al2O3 Sillimanite Ceramic Furnace Pipes for Kilns
Detailed specification for Porous Alumina Al2O3 Sillimanite Ceramic Furnace Pipes for Kilns
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | YN-265 |
| Shape | Square, Tubular, Oval, Rectangular, Half |
| Use | Furnace, Refractory, Heat Coil, Wire Coil |
| Temperature | 1000-1300c |
| Type of Ends | Both Ends Open Obe or Beo |
| Machining of Ceramic Tube | Drill Hole, Notch or Slot, Flange, Collar, Thread, Spir |
| Material | Alumina Ceramic |
| Type | Ceramic Tubes |
| Transport Package | Plywood Case |
| Specification | OD 6-100 |
| Trademark | Yunnuo |
| Origin | China |
| HS Code | 8547100000 |
60% -85% Alumina ceramic furnace tube,Mullite ceramic pipe, Sillimanite refractory ceramic tube
Our tubes are manufactured from 75% -85% al2o3 with high temperature resistance about 1300-1400C.
Production process:
Selection of raw material-crushing and batching-adding binder-forming-drying-firing
Application:
Furnace tube,resistor tube,roller
Building ceramics, daily-use ceramics, rare earths, electronic ceramics and glass ceramic roller kiln.
Material data:
Item name
BL-S
BL-V
BL-C
BL-D
Density g/cm3
2.75-2.8
2.73-2.75
2.7-2.74
2.6-2.7
Rupture strength Mpa
65-75
55-65
50-60
48-58
Water absorption
5-6.5%
6-7.5%
6.5-8.5%
7-9%
Max using temperature (roller kiln)
1400C
1350C
1300C
1300C
Refractoriness
1800C
1750C
1700C
1700C
Al2o3 content
76-80%
75-77%
75-80%
60-70%
Zirconium silicate
4-7%
4-6%
0
0
Specification:
ODxID in mm
13x6
15x8
16x10
18x12
22x14
25x15
30x16
27x17
28x18
30x20
35x25
40x25
40x30
42x31
45x34
50x39
55x43
60x48
65x52
70x56
75x60
80x65
85x70
90x75
95x80
100x84
105x85
110x90
120x110
We can cut length according to your requirement.We can also make to order.
