Porosity Customizable Porous Sic Ceramic Filtration Tubes Liquid Filter Pipes

Model NO.	HKCA59
Length	Customized
Name	Microporous Ceramic Filter Sleeves
Size	Customized
Shape	Round
Appearance	Neat
Surface	Smooth
Property	High Wear Resistance
Advantage	Long Working Life
Certificate	RoHS
Porosity	45%
Usage	Aroma Volatile
Performance	Stable
Other Material	Porous Ceramic
Key Word	Porous Ceramic Filter Tubes
Material	Other
Transport Package	Safe Package
Specification	custom
Trademark	OEM
Origin	China
Production Capacity	200000piece Per Month

Product Description

The main raw materials of microporous ceramics include alumina, silicon carbide, corundum, diatom and so on. We can produce products of various shapes according to customers' requirements or drawings. Pore size and porosity can be customized.

porous ceramic filter :





Microporous ceramic filter products is made through special process special ceramics products, consisting of many distributed evenly microporous porous structure, when fluid from the tiny holes through, suspended substance, colloid particles, macromolecular organic matter trapped in the filter medium surface, achieve mechanical screen LvJingHua or diffusion, fluidization effect and so on.

Porous Ceramic Filter Tubes:
Microporous ceramic filter products with resistance to corrosion, high temperature resistant, the characteristics of high mechanical strength, no harmful dissolution, does not produce secondary pollution, under the effect of fluid pressure, pore deformation, easy cleaning, long service life, alternative cotton, silk, plastic, metal mesh, stone cotton, such as filter material, widely used in petroleum, chemical industry, metallurgy, thermal power, cement, medicine, paper making industries.



Product Parameters



Item Infiltration Cup
Plant Water Absorbing Wick
Electrode Wick
Ceramic Wick
Scented Ceramic
White alumina
Silicon Carbide

(g/cm³)Density

1.6-2.0 0.8-1.2 1.8-2.2 0.8-1.2 1.6-2.0 1.7-2.0 (%)
Open Porosity Rate 30-40 50-60 20-30 40-60 30-45 35-40 (%)
Porosity Rate 40-50 60-75 25-40 60-75 40-50 40-45 (%)
Water Absorption 25-40 40-70 10-28 40-70 25-40 25-35 (μm)
Pore Size 1-5 1-3 1-3 1-3 1-5 1-10
