Product Overview
Detailed specification for PPR Fittings for Plumbing Fusion Fittings Equal Tee PPR Fittings
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | M-8 |
| Type | Equal |
| Connection | Fusion |
| Material | PP-R |
| Shape | Equal Tee |
| Lateral | 90°Tee |
| Head Code | Round |
| Technics | Injection |
| Pressure Rating | Pn25 |
| Standard | GB |
| Certification | ISO, CE |
| Colors | Green, White, Grey, Yellow |
| Working Temperature | Max.95 |
| Working Pressure | Pn25 |
| Transport Package | CTN Boxes, Bags |
| Specification | 20-160mm |
| Trademark | MINGSHI/OEM |
| Origin | China |
| HS Code | 3917400000 |
| Production Capacity | 5000 Tons/ Year |
| PPR fittings | |
| Warranty | More than 10 years |
| Certification | ISO, CE |
| Application | Hot/ Cold water, Plumbing |
| Customized support | OEM, ODM |
| Place of Origin | China, Zhejiang |
| Brand Name | OEM/MINGSHI/MSP |
| Model Number | M-6 |
| Standard | ISO/ other |
| Technics | Injection |
| Connection | Fusion |
| OD | 20mm/ 25mm/ 32mm/ 40mm/ 50mm/ 63mm/ 75mm/ 90mm/ 110mm |
| Materials | HYOSUNG/ Other |
| Colors | Green/ white/ grey/ yellow |
| MOQ | 1000pcs |
PPR Fittings
Made of high quality polypropylene random, applied in both residential and commercial buildings, bringing a more hygienic and securer plumbing experience to customers worldwide.
1. Advantages:
Applied for potable water pipeline system with hygienic and non-toxic features, high temperature and high pressure resistant, lighter and smoother than the metal pipe, noice free, economic in cost, easy and quick installation.
2. Sizes range from 16-160mm, with different wall thinkness for different pressure applies.
3. Colors can be green, blue, white, etc, or different colors in inner and outer layers.
4. Accurate tolerance control ensure a perfect hot welding joint
5. Certified by ISO9001.
6. Inspected on every material lot, and every piece of finished products.
7. Tested by systems before shipped out.
8. 3rd party product liability Global Insurance.
| Essential details |
| Place of Origin: | Zhejiang,China | Material: | PPR |
| Specification: | 20-160MM | Length: | 4/5/6 or OEM |
| Thickness: | SDR5/4/3.2/2.5 | Standard: | ISO,DIN |
| Processing Service: | Extrusion | Product name: | Plastic pipe fittings |
| Application: | Water system | Type: | Plastic Building Material |
| Raw Material: | PPR | Colors: | White,Green,Grey or OEM
|
| Logo: | Support custom logo | Features: | Corrosion Resistant,high pressure |
| MOQ: | 5000m | Shape: | Round |
| Advantage: | Flexible,easy to install | | |
| Supply Ability |
| Supply Ability: | 1000000 Meters per month |
| Packing&Delivery |
| Packing Details: | Plastic bag |
| Port: | Ningbo or Shanghai |
| Nominal diameter | Tolerance | Nominal Wall Thickness |
| dn | dem,min | dem,max | PPR pipe |
| SDR | S5 | S4 | S3.2 | S2.5 |
| 20 | 20 | 20.3 | 2 | 2.3 | 2.8 | 3.4 |
| 25 | 25 | 25.3 | 2.3 | 2.8 | 3.5 | 4.2 |
| 32 | 32 | 32.3 | 2.9 | 3.6 | 4.4 | 5.4 |
| 40 | 40 | 40.4 | 3.7 | 4.5 | 5.5 | 6.7 |
| 50 | 50 | 50.5 | 4.6 | 5.6 | 6.9 | 8.3 |
| 63 | 63 | 63.6 | 5.8 | 7.1 | 8.6 | 10.5 |
| 75 | 75 | 75.7 | 6.8 | 8.4 | 10.3 | 12.5 |
| 90 | 90 | 90.9 | 8.2 | 10.1 | 12.3 | 15 |
| 110 | 110 | 111 | 10 | 12.3 | 15.1 | 18.3 |
| 125 | 125 | 126.2 | 11.4 | 14 | 17.1 | 20.8 |
| 140 | 140 | 141.3 | 12.7 | 15.7 | 19.2 | 23.3 |
| 160 | 160 | 161.5 | 14.6 | 17.9 | 21.9 | 26.6 |
Primary ProductPPR Fittings for Plumbing Fusion Fittings Equal Tee PPR Fittings
Contact PersonMissCiciFu
Minimum Order1000 Meters
PaymentsLC, T/T, PayPal, Western Union
DeliveryContact the supplier about freight and estimated delivery time.
Origin5/F, Blk 3, Mingshi Plaza, 8 Mingshi Rd, Diankou Town, Zhuji City, Shaoxing, Zhejiang, China CTI Audit Report No.
PackingCarton Box+Plastic Bag
InspectionGB
SamplesProvide Samples
For faster quotation, share your preferred specification, target quantity, destination and packaging requirements when contacting the supplier.
FAQ
Frequently Asked Questions
Find quick answers about samples, payment, delivery, packaging and quality assurance before placing an order.
Q1: May I get one sample before placing order?
AYes, Sample are available. For normal products, samples are for free and you just need to bear the freight; For those high value products, you just need to freight and certain product cost. When we both cooperate for some times or when you are our VIP customer, free sample will be offered when you need.
Q2: Which payment is available for your company?
AT/T, L/C or Ali trade insurance. You can choose the one which is convenient for you.
Q3: How and when can I get my goods after payment?
AFor small quantity products, they will be delivered to you by international courier(DHL, FedEx, TNT etc.) or by air. Usually it will cost 3-5days that you can get the goods after delivery. For large quantity products,shipping by see is worthwhile.It will cost days to weeks to come to your destination port, which depends on where the port is.
Q4: Is there any possible to use my appointed label or package?
AYes. If needed, we'd like to use label or package according to your requirement.
Q5: How can you guarantee the goods you offer is qualified?
AWe always believe honesty and responsibility are basis of one company, so whatever products we provide for you all are qualified. We will have goods tested and provide COA before delivery for sure.
Q6: Is the price on this page correct?
AThe listed price is only for reference, for latest price, pls contact us directly.
Q7: How can I get some samples?
AWe are honored to offer you free samples, just need to pay the freight cost.
