IP65 Integrated with The Internet of Things LED Street Fitting
Detailed specification for IP65 Integrated with The Internet of Things LED Street Fitting
Review product features, application details and supporting information below. For pricing, samples or shipping questions, use the inquiry form on this page.
| Model NO. | RT15 |
| Application | Street/Road/Port/Garden |
| IP Rating | IP66 |
| Certification | CE, PSE, RoHS, UL |
| Input Voltage | AC90-300V |
| LED Chips Brand | CREE |
| PF | ≥0.9 |
| LED Light Source | SMD3030/5050 |
| Lamp Luminous Efficiency(Lm/W) | 100—200 |
| Lifespan | >50000hours |
| Warranty(Years) | 3/6 |
| Wattage | 50W—200W |
| Transport Package | Carton |
| Trademark | DNA/OEM |
| Origin | Changzhou, China |
| Production Capacity | 1000000PCS/Year |
Parameters
Model
RT15-50W
RT15-100W
RT15-120W
RT15-150W
RT15-200W
Power
50W
100W
120W
150W
200W
Input Voltage
AC90—300V
AC90—300V
AC90—300V
AC90—300V
AC90—300V
LED Type
3030/5050
3030/5050
3030/5050
3030/5050
3030/5050
Lumen/Wattage
100—200
100—200
100—200
100—200
100—200
Anti-surge
10KV
10KV
10KV
10KV
10KV
Power Factor
≥0.9
≥0.9
≥0.9
≥0.9
≥0.9
CRI
>80
>80
>80
>80
>80
Color Temperature
1800—7500K
1800—7500K
1800—7500K
1800—7500K
1800—7500K
0—10V Dimming
Available
Available
Available
Available
Available
Start Time
<0.5s
<0.5s
<0.5s
<0.5s
<0.5s
IK
10
10
10
10
10
IP Rating
66
66
66
66
66
Beam Angle
60°/90°/120°
60°/90°/120°
60°/90°/120°
60°/90°/120°
60°/90°/120°
Housing Color
Black/Grey
Black/Grey
Black/Grey
Black/Grey
Black/Grey
Working Temperature
-45 ℃—+65 ℃
-45 ℃—+65 ℃
-45 ℃—+65 ℃
-45 ℃—+65 ℃
-45 ℃—+65 ℃
Humidity
10%~95%RH
10%~95%RH
10%~95%RH
10%~95%RH
10%~95%RH
Body Material
Aluminum alloy
Aluminum alloy
Aluminum alloy
Aluminum alloy
Aluminum alloy
IES File
Available
Available
Available
Available
Available
Life Time
>50000Hours
>50000Hours
>50000Hours
>50000Hours
>50000Hours
Warranty
3/6 Years
3/6 Years
3/6 Years
3/6 Years
3/6 Years
Dimension L*W*D(mm)
500*245*75
500*245*75
615*298*83
615*298*83
615*298*83
Net Weight(kg)
3.0
3.2
3.5
4.0
4.5
Characteristics
*FT15 is a stylish LED Street Light, unique design, streamlined housing&tempered glass cover,super weather proof.
*It has a heavy duty aluminum alloy body, it is good at heat dissipation, ensures the lamp works up to 200 Wattage.
*It has a big and strong electrical cabinet, it is able to load most of the famous drivers&components on the market.
*It also has a mounting sleeve adjustable version, the installation angle is good to adjust according to requirement.
