On the basis of internation advanced technology form the developed countries, we produced the C-PVC, PPR, PE pipe bending machine independently. This machine can be used to instead of traditional cpvc fitting injection machines. And this machine can save cost about 50% than injection machines. We aims to make high quality machines with reasonable price.
This machine can bend the pipes to bridge shape. Technical Parameters 1Pipe Outer DiameterOD20mm,25m,32mm 2Heating MethodCeramic infrared heating 3Heating Power10kw 4Heating station2 5cooling methodair cooling    6Forming typeBend bridge shape 7inserting station3×2 8hydrailic oil 46# wear resistance hydraulic oil 9Max heating temperature300ºC 10Air pressure 0.4-0.6Mpa 11Water pressire0.2-0.3Mpa 12Total power14kw 13Working methodSemi-automatic 14This machine can bend 5 pcs of pipe each time



Main electronic Components 1Oil Pump    2Hydraulic CylinderYolon   3Hydraulic Valve    4Pneumatic ComponentsAirtic   5PLCSiemens   6Touch ScreenSiemens   7Contactor SwitchSchneid er   8Auxiliary RelaySchneid er   9Photoelectric SensorAutonics   10Proximity SwitchAutonics   11Temperature ControllerRKC   12Dimension1650*1900*1630mm
