Model NO.	DN16-DN160mm
Water Absorption	＜0.01%
Contraction Percentage	＜0.4%
Tensile Strength	30~40MPa
Color	White ; Green
Welding	Hot-Melt Welding
Temperatures	-30°c to 90°c
Advantage	Eco-Friendly;Resistant to Corrosion
Transport Package	Woven Bag or Caton
Specification	DN20-DN160mm
Trademark	Shangze
Origin	China

Product Description

PPR pipe is a new type of eco-friendly piping material for both hot and cold water. It's resistant to corrosion and buildup, and its smooth interior reduces water flow resistance. Made from polypropylene, it can handle temperatures from -30°C to 90°C. PPR pipes are joined using a hot-melt welding process, creating a strong and seamless connection. Available in white and green, these pipes come in various sizes from 16 to 160. They are ideal for both household water supply systems and large-scale construction projects.
PPR drinking water pipe is commonly used in developed countries, it uses homogeneous welding technology in hot and cold water transportation projects, and its comprehensive technical performance and economic indicators are far superior to other similar products. Particularly, its excellent sanitary performance, from the production to the waste recycling process can reach extremely high sanitary and environmental protection requirements.


Product Parameters

ProjectIndicators

 Test methodsNote:
1.Using a metal threaded inserts with a corrosion-resistant to connect plastic pipe fittings with metal pipes and water heater. pipefittings  Density  g/cm3 (20ºC)0.89-0.91BG/T 1033 Thermal Conductivity(w/m.k.    )0.23-0.24BG/T 3399 Coefficient of linear expension (mm/mk)0.14-0.16BG/T 1036 Modulus of elastivity Nmm2  20ºC800BG/T1040 Tensile strength Mpa≥20BG/T 1040 Longitudinal reversion (135ºC±2ºC   )≥2%BG/T 6671 Charpy impact test 15j 0±2ºC Breakage rate <10%BG/T 18743
Hydraulic Test Tube20ºC 1h  16mpa  No leakage no ruptureNo leakage no rupture 9ºC 22h  4.2mpa 95ºC  165h  3.8Mpa Socket connection seal test    Experiental stress of 2.4 times the nominalBreakage rete<10%

Outside diameter mmThe average allowable deviation mmWall thickness (e) Pipe series S5(1.25mpa)S4(1.6mpa)S3.2(2.0mpa)S2.5(2.5mpa) 16+0.3-2.02.2  20+0.32.02.32.83.4 25+0.32.32.83.54.2 32+0.32.93.64.45.4 40+0.43.74.55.56.7 50+0.54.65.66.98.3 63+0.65.87.18.610.5 75+0.76.88.410.312.5 90+0.98.210.112.315.0 110+1.010.012.315.118.3 160+1.514.617.921.926.6

Detailed Photos

Product advantage

 Material is polypropylene, it is    a new type of eco-friendly piping material

It can handle temperatures from -30°C to 90°C

color: green  white

welding: hot-melt welding process



Application

1.hot and cold water piping system for building
2.Direct use of pure water supply system.
3.Central air conditioning system
4.Transport and discharge industrial chemical medium
5. The building wall board, and floor radiation heating system.
