Product Introduction

PVC.U Environmental-Friendly Drainage Pipes
The pipe material has excellent surface hardness and tensile strength, ensuring a high level of pipeline safety.
It has good aging resistance, with a normal service life of up to 50 years.
The pipe demonstrates strong corrosion resistance against inorganic acids, alkalis, and salts, making it suitable for industrial sewage discharge and transportation.
Its inner wall is smooth and small in diameter, reducing the risk of clogging and minimizing maintenance needs.
The material has a high oxygen index and is self-extinguishing.
The linear expansion coefficient is low-only 0.07 mm/m per °C-making it less affected by temperature changes.
With low thermal conductivity and a small elastic modulus, its anti-freeze performance is superior to that of cast iron drainpipes.
Pipes and fittings can be joined using adhesive, and the construction process is simple, easy to operate, and highly efficient.


Product Specification Size Table OD
mmAverage Outside DiameterThickness
mm Min. OdavgMax. Odavg 323232.22.0 404040.22.0 505050.22.0 757575.32.3 909090.33.0 110110110.33.2 125125125.33.2 160160160.34.0 200200200.54.9 250250250.56.2 315315315.67.8 The following are standard dimensions. Custom sizes are available upon request.
