| Model NO. | Plastic Electrical Junction Box Injection Mold |
| Plastic Material | PVC |
| Application | Household Appliances, Electronic, Home Use |
| Runner | Cold Runner |
| Design Software | Autocad/Ug/Solidworks |
| Installation | Fixed |
| Certification | CE |
| Customized | Customized |
| Product Name | Plastic Electrical Junction Box Injection Mold |
| Mould Running | Fully Automatic |
| Fitting Size | 32mm/40mm/ 50mm/63mm/ 75mm/90mm/110mm/160mm... |
| Moulding Material | PVC |
| Product Standard | En1401 En1329 GB/T 5836 ISO 3633 ISP1452 Sans 791 |
| Cavity Number | 1/2/4/8...... Customized Requiredments Is Welcomed |
| Steel of Core and Caity | Germany Steel 1.2316 /China1.2316/4Cr13/3Cr13 /P20 |
| Steel of Mould base | S50c/S45c/Lkm |
| Mould Accessories | Dme/Hasco Standard |
| Surface Finish | Diamond Polish |
| Mould Ejector Way | Ejector Pin/ Ejector Plate / Air Valves / Slide |
| Surface Treatment | Polish / Etched |
| Mould Heat Treatment | Tempering / Quenching/ Nitriding |
| Core Pulling System | Hydraulic Motor |
| Transport Package | Standard Packaging or Customized |
| Specification | Standard or Customized |
| Trademark | Customized |
| Origin | Zhejiang, China |
| Production Capacity | 500000pieces/Year |
Corrosion Resistance Custom Made Electrical Boxes Conduit Fittings UPVC Injection Mould
Product Description
A Plastic Electrical Junction Box Injection Mold is a specialized mold used in the manufacturing of electrical junction boxes made from plastic material. Electrical junction boxes are important components in electrical wiring systems as they provide a protective enclosure for electrical connections and help ensure safety and organization within an electrical system.
The injection mold is a tool that is used to shape molten plastic material into a specific design or shape. In the case of a plastic electrical junction box injection mold, it is designed to produce electrical junction boxes with precise dimensions, features, and functionalities. The mold is typically made of durable materials such as steel and is engineered to withstand the high temperatures and pressure required during the injection molding process.
During the injection molding process, plastic pellets are heated and injected into the cavity of the mold under high pressure. The plastic material then solidifies and takes the shape of the mold cavity, resulting in a finished electrical junction box product.
The mold may include various features such as channels for wiring, mounting holes, and other components specific to the design of the junction box. Being recognized as the most trustable plastic mold manufacturer and a provider of valuable customer services, we are proud of our growth over the years. We have invested our time and money into our business and our devotion and loyalty to our customers to bring about the best results. We have a trained set of workers who have sharp skills to help us with mold-related queries and provide us with their best efforts to bring innovation.
Product Parameters
Detailed Photos
Precision Manufacturing
Molds ensure consistent and precise dimensions for the junction boxes, which is critical for proper fit and function in electrical installations.
Durability
High-quality molds are designed to produce strong and durable junction boxes that can withstand environmental stresses, ensuring longevity and reliability in electrical systems.
Design Flexibility
Molds can be customized to produce boxes of various shapes and sizes, allowing manufacturers to meet specific project requirements and adapt to different applications.
Efficient Production
Using molds enables high-volume production of junction boxes, improving manufacturing efficiency and reducing lead times for projects.
Material Variety
Molds can be used with various materials (such as UPVC, PVC, or other plastics), allowing manufacturers to choose the most suitable material for the intended application based on factors like durability, cost, or environmental considerations.
Jingzheng Advantages
1. JINGZHENG has many different types of Collapsible core system2. Fitting ranges from 32mm to 315mm
3. Patented collapsible core system enable the fitting to be demoulded smoothly
4.Guarantee high precision , with long-time mould life, flash-free and flawless fitting
5.Free sample delivery
6.Every week update production informations.
7.Mould one year quarantee in normal condition use,Mould full-life technique support.
8.Testing mould in our factory
