| Material | PVC |
| Kind | Thermosetting Plastics Pipe |
| Water Absorption | ＜0.01% |
| Contraction Percentage | ＜0.4% |
| Tensile Strength | 41~50MPa |
| Product Name | PVC Pipe |
| Color | Black, White or Blue |
| Package | 20' or 40' Container |
| Standard | GB/T10002.1-2006 |
| Pressure | Pn5, Pn6, Pn8, Pn10, Pn12.5, Pn16, Pn20, Pn25 |
| Feature | Self-Extinguishing, Acid Resistance, Moisture Resi |
| MOQ | 500m or Negotiation |
| Certificate | CE, SGS, ISO, CNAS, IAF |
| Specifications | Od50 to 315 |
| Lifespan | Over 50 Years |
| Working Temperature | - 40℃ to 40℃ |
| Strength | High Strength |
| OEM | OEM Orders Accepted |
| Application | Conveying Water |
| Shape | Round |
| Transport Package | Standard Export Packing |
| Specification | DN20-1600 mm |
| Trademark | DRD |
| Origin | Tianjin, China |
| HS Code | 3917230000 |
PVC pipe:
200mm Blue PVC Pipe PVC-UH Pipe for Potable Water Price
PVC Pipe, PVC Pressure Water Pipes are produced in the two groups as PVC Pipe self socket with seal and PVC Pipe solvent cement socket. U-PVC Pipes mostly drinking water, sewage, irrigation, chemical industry in the area is preferred. PVC pipes produced according to ISO 1452-2, DIN 8061 - 62 standards and the standards of the projects also can be produced.
PVC pipes due to light and self-muffle features makes installation quickly and provide use. It doesn't deform due to their resistance to impacts and used for a long time. Because the gasket supplied with the bonding method applicable they do not leak from the outside or the inside. PVC pipes produced as PN 6 - PN 10 - and PN 16 are produced in 6 meters long. In shipments of container 5.8 tube lengths to be produced in accordance with the container size shipping costs are minimized.
Advantages:
1.The PVC pipe easy to installation for underground due to light characterized
2.PVC pipe can be prefered in big depth of the underground because of their strong speciality,
3.The value of SN numbers on the PVC pipes can be adapt very easy to the Sewage lines for years.
4.Due to light advantage of PVC Pipes, it's easy to loading and unloading to the vehicles for transportation of them.
5.Pvc Pipes can be manufacture in desired size, pressure numbers and thicknesses according to projects needed,
6.PVC pipes also used as perforated pipes on the drainage projects
Specification in National Standard:
Normal Diameter (DN/OD) (mm)
Wall thickness (mm)
PN6.3
PN8
PN10
PN12.5
PN16
0.63MPa
0.8MPa
1.0MPa
1.25MPa
1.6MPa
20
1.5
25
1.5
2
32
1.6
2
2.4
40
1.5
1.6
2
2.4
3
50
1.6
2
2.4
3
3.7
63
2
2.5
3
3.8
4.7
75
2.3
2.9
3.6
4.5
5.6
90
2.8
3.5
4.3
5.4
6.7
110
2.7
3.4
4.2
5.3
6.6
125
3.1
3.9
4.8
6
7.4
140
3.5
4.3
5.4
6.7
8.3
160
4
4.9
6.2
7.7
9.5
180
4.4
5.5
6.9
8.6
10.7
200
4.9
6.2
7.7
9.6
11.9
225
5.5
6.9
8.6
10.8
13.4
250
6.2
7.7
9.6
11.9
14.8
280
6.9
8.6
10.7
13.4
16.6
315
7.7
9.7
12.1
15
18.7
355
8.7
10.9
13.6
16.9
21.1
400
9.8
12.3
15.3
19.1
23.7
450
11
13.8
17.2
21.5
27.7
500
12.3
15.3
19.1
23.9
29.7
560
13.7
17.2
21.4
26.7
630
15.4
19.3
24.1
30
Density
1350-1460
Vicat softening temperature
≥80ºC
Longitudinal shrinkage
≤5%
Drop hammer impact test
0ºCTIP≤5%
hydrostatic test
No rupture, no leakage
Connection seal test
No rupture, no leakage
Shading experiment
light-proof
VCM content
≤1mg/kg
Flexural Strength (Mpa)
≥36
1. Civil construction, industrial building indoor water supply, and waste water drainage and sewerage system.
2. The residential area, plant area of buried water supply system.
3. The urban water supply pipeline system.
4. Water treatment plant's water piping system.
5. Mariculture.
6. Garden irrigation, drilling engineering, and other industrial pipe.
Details of the pvc water pipe:
