Plastic Reinforced UPVC/PVC Pipe Hose Tube Making Machinery

Product Description

General introduction:
The extrusion line is used to produce PVC wire reinforced transparent hose. The hose wall is made of transparent PVC plastic. In the hose inner-wall, there are spiral plastic.
The kind of hose has the advantage of extrusion resistance, corrosion resistance, static electricity resistance, anti-high pressure and good running.
It is suitable for the conveying high pressure or combustible gas and liquid, heavy suction and delivery of liquid sludge. It is mainly used in the fields machinery, such as chemical industry, building, irrigation and vacuum pumps, etc.

Features:
1. The special design of high speed, high efficiency extruder, to ensure the quality and output of the material.
2. Special design of the wire wind spring machine, uniform spring, continuous production time is long.
3. The special design of the pipe head, the production of high transparency, wire distribution uniformity, the length can be arbitrarily set.
4. The main unit of the main electrical components are imported products, stable and reliable operation.
5. The unit of all keys using integrated design, operation is simple and quick.

Process flow:
Raw material + additive → mixing → granulating → conveying feeding→ single screw extruder→ steel wire forming machine→ extruding mold → spray cooling tank→ belt haul-off → winder → finished product inspecting & packing

Technical parameters:

Extruder model Pipe diameter range Total power Output of extruder SJ55 12mm-20mm 30kw Around 35kg/h SJ65 20mm-50mm 40kw Around 60kg/h SJ90 50mm-75mm 50kw Around 100kg/h

Packaging and shipping:
