| Model NO. | Reinforced Nylon Fabric Duct Hose |
| Color | Color |
| Pressure | 0.8bar |
| Transport Package | Catain/Pallet/Braided Paper Bags |
| Specification | 2"-24" |
| Trademark | HERO POWER/RUNNINGFLEX/SUPER WELL/EVERFLY |
| Origin | China |
| HS Code | 40093100 |
| Production Capacity | 850, 000 Meters Per Month |
Nylon fabric duct hose is designed to exhaust fumes, light weight dust as well as for air movement. This flexible ventilation hose is produced by PVC coated nylon polyester fabric with spring steel wire. Such air ducting hose is light in weight and flexible with high tensile strength. Besides, it resists vibration and tearing.
Fabric duct hose Structure:
Wall: pvc coated nylon fabric
Spiral: high strength and elastic steel wire
Working temperature: -15 to +130ºC
Flexible Duct Hose Specs:
Inner diameter: 2″-24″
Thickness: 0.35mm
Steel wire diameter: 0.8-2.3mm
Length: 10m/roll
Such flexible duct hose adopts imported nylon fabric as the raw material. While it's the latest material in the world. Thus the fabric duct performs much better than normal venting hose. Besides, there is flame retardant PVC coating on the both sides of the duch hose pipe. Thus the hose is flame retardant. Which means it will extinguish once away from the fire. Then there is high strength and elastic steel wire supports inside. Thus the structure will be strong enough to bear the external pressure and impact. The connection between steel wire and nylon fabric is hot melting. Thus the 2 part closely bond with each other.
Duct Tubing Application:
Ideal for ventilation of fumes, dust extraction & collection and air movement.
AC and light duty dust extraction
As a flexible connection between grilles diffusers, fans as well as other units
Suction of engine exhaust gas
Exhaust gas technique, engine construction, engine warming, aircraft and military
For flue gas extraction, blast furnace exhaust and engine test bench
Canvas Duct Features:
Vibration, tearing and aging resistant
High temperature, acid and alkali resistant
High tensile strength
Flame retardant
Highly flexible and compressible up to 10:1
Self-distinguish
Highly flexible and light in weight, asy to install and transfer
Wear resistant and durable
Certificate
