| Model NO. | HDPE water supply pipe-big size |
| Material | PE |
| Kind | Thermoplastics Pipes |
| Water Absorption | ＜0.01% |
| Contraction Percentage | ＜0.4% |
| Tensile Strength | 3.9MPa |
| Mini Order | 100m |
| ISO | 9001 |
| Size | 16-1600 |
| Delivery Time | 10 Days |
| Transport Package | Plastic Bag |
| Specification | 16-2000MM |
| Trademark | fosite |
| Origin | China |
HDPE Water Supply Pipe
Specification: OD20mm-OD2500mmPressure: 0.32Mpa-2.0Mpa
Length: 5.8m/11.9m or as required
Standard: GB/T13663-2000, ISO4427-1:2007
Material: High Density Polyethylene
Color: Black or as required
Product Description
HDPE pipe is a perfect solution for municipal engineering system and urban water supply and drainage system. HDPE pipe adopts high-quality original PE100 or PE80 raw material with the size range of DN 20-2500mm, and the performance conforms to ISO4427 standard and other national certification standards. HDPE pipes for water supply can be manufactured with different rated pressures mainly: SDR26/0.6MPa, SDR21/0.8MPa, SDR17/1.0MPa, SDR13.6/1.25MPa, SDR11/1.6MPa, etc.Features
Our HDPE pipe for water and sewer is manufactured for excellent performance and a long life expectancy.1. High resistant to corrosion and weather, recent studies conclude it will last at least 50 years.
2. Its light weight and flexibility make it easy to install, eliminating the need for fittings required with directional changes, and make it highly suitable for use in earthquake prone areas.
3. Its high-strength walls give it the highest PE pressure rating, outstanding resistance to SCG and increased resistance to rapid crack propagation.
4. The increased working stress rating of high-performance PE resin material makes it a superior choice over steel or ductile iron pipe, especially for the large diameter pipe sizes.
Specification
Applications
1. Municipal engineering water supply and drainage.2. Chemical industry water supply and drainage.
3. Mining area slurry transportation.
4. Farmland irrigation and animal husbandry.
5. Fish farming & breeding system.
6. Seawater desalination & water treatment.
Precautions
DO :Keep the pipes and fittings away from sharp objects, heat sources and toxic and corrosive materials.
Before installation, keep the protective packaging intact.
Prevent dust or other materials from entering the pipe.
DO NOT :
Throw pipe from delivery vehicles.
Place pipe and fittings incontact withlubricating oil, gasoline, solvents or other aggressive materials.
Heat pipe with an open flame.
