I.Automatic induction showerFunction characteristics
1、Water conservation: Automatically detects human presence and absence, stopping water flow when a person is present and resuming when they leave, resulting in significant water savings, exceeding 30% to 50%.
2. Hygiene: Water is dispensed directly from the nozzle upon contact, and the water supply stops automatically when the person leaves. This effectively eliminates cross-contamination from bacteria.
3、Waterproof: Utilizes a fully sealed epoxy resin encapsulation, ensuring long-term durability.
4、Anti-fogging, winter anti-fogging technology, particularly suitable for low-temperature environments in northern regions.
5、Close-proximity protection: Patent-protected anti-obstruction function to prevent interference from nearby objects, thereby avoiding water leakage.
6. Easy to maintain, with strong anti-scaling and anti-fouling properties. The spray nozzle features a removable filter at the inlet, allowing for easy maintenance by non-professionals.
7. Intelligent, the sensor utilizes a microcontroller for control, and the sensing range is pre-set upon factory exit, eliminating the need for manual adjustment.
8、Safety: This product uses 24V safe DC power, ensuring safety and reliability. The shower nozzle and elbow are designed with an upward water outlet and are fixed by a dedicated bracket, preventing accidental pulling or damage.
9、Easy to install, suitable for a variety of new and renovated bathtubs.
Two. How to use the induction shower.
1、The infrared-sensing shower heads used in bathtubs operate by detecting infrared signals. When a person or other object is within a certain distance of the shower head, the emitter emits an infrared signal that is reflected back by the human body or object. The infrared receiver then analyzes this reflected signal, and if a valid signal is detected, the sensor instructs the electromagnetic valve to open, activating the water flow. If no valid signal is detected, the valve remains closed.
2. When the human body enters the effective sensing range, the controller automatically emits a signal to open the switch of the electromagnetic valve or electric valve, enabling automatic drainage.
3. After the user leaves, the controller automatically sends a signal to close the switch of the electromagnetic valve or electric valve, stopping the water flow. This eliminates the problem of leaving the faucet running while bathing or washing, significantly reducing water consumption.
4、The effective distance for the sensor is 5-80cm. The 0-5cm range provides anti-obstruction functionality to prevent someone from intentionally blocking the sensor with a towel, such as during prolonged water flow. The sensor distance can be adjusted according to individual needs using a remote control.
