I.Toilet water-saving deviceHow to install
1、Installation of water-saving devices in restrooms - Preparation
(1) First, verify the model number of the water-saving device and then check the integrity of the surface and ensure all accessories are present. Continue to check the quantity of parts.
(2) Prepare the installation toolkit, conduct an on-site inspection of the installation environment, and plan the installation location and confirm the installation scheme.
2、Installation of water-saving devices in restrooms - measurement data
(1) First, use a measuring tape to accurately measure the required dimensions and collect the data. Then, organize the data and clearly mark the corresponding locations.
(2) Then, use a drill to create holes at the specified locations, paying attention to the depth and spacing of the holes, and ensuring they are compatible with the size of the screws to be installed.
3、Installation and fixing of water-saving devices in toilets.
(1) Secure the microcomputer program controller and infrared detector to the wall using screws. The detector can be mounted on the wall or ceiling, and the infrared sensor should be aligned with the jamb or basin step.
(2) Then, install the electromagnetic valve on the water inlet pipe, paying close attention to the water inlet direction, filter mesh connections, and other relevant details. Ensure that these are installed correctly.
(3) Connect the electromagnetic valve and infrared detector to the terminal block of the microcomputer controller, and then connect the AC 220V power supply to the terminal block of the microcomputer controller.
(4) After the overall installation is complete, perform a comprehensive inspection. If no issues are found, allow it to operate and monitor for any further problems. If any issues arise, troubleshoot and correct them before resuming normal operation.
II. How to renovate a bathroom for water conservation
1、Install flow control valves on faucets.
Currently, most households use lever-type faucets in their kitchens and bathrooms. These faucets can be difficult to control, leading to increased water usage. A solution is to install a flow control valve under the faucet. This allows for the appropriate regulation of water flow based on the household's water pressure, thus conserving water while maintaining optimal water flow and comfort.
2、Use the bathtub and shower together.
In people's perception, showers are more water-efficient than bathtubs. However, from a practical perspective, installing new, water-efficient bathtubs and using them in conjunction with showers can achieve a "one-water-for-multiple-uses" effect, leading to better water conservation. Bathtubs primarily save water through circulation and volume. Bathtubs with lengths of 1.5 meters or less, even though they are deeper than standard bathtubs, are more water-efficient. Furthermore, bathtubs designed with ergonomic seating options minimize water loss. Their smaller bottom area makes it easier to stand in, particularly suitable for the elderly and children. When used in conjunction with showers, this allows for a "one-water-for-multiple-uses" effect.
3、Install men's urinals
If your home has men living there and the bathroom is relatively spacious, we recommend installing a urinal alongside the toilet. This is a good option from both a water conservation and hygiene perspective. Installing a urinal is not only convenient for seniors and children but also prevents contamination of the toilet and provides a safe and hygienic environment. Furthermore, it can save water, as the amount of water used per flush is significantly less than that of a toilet.
