One, Installation method for freestanding massage bathtubs without wall support.
1. Preparation Phase
(1) First, inspect the installation environment for the Jacuzzi, estimate the available space, and purchase a Jacuzzi of the appropriate size to avoid installation issues due to insufficient space.
(2) Verify the model and quality of the massage bathtub, check if it meets the requirements, count the number of accessories, and read the installation instructions in advance.
2. Laying the foundation
(1) According to the installation diagrams and specified dimensions, install wooden or aluminum strips as support points at the installation location. After the cement mortar has fully cured, prepare for the application of bricks to the wall and floor/wall.
3. Installation and Fixing
(1) If using a bathtub-mounted faucet, before installing in the bathtub, fix the faucet body and water flow control valve to the bathtub, and connect the water supply pipe after the bathtub is placed.
(2) The connection must be tight. Waterproof tape can be applied to the joint between the bathtub and the floor to enhance its waterproofing and sealing performance. A maintenance hole should be pre-cut on the wall near the faucet, with dimensions approximately 30cm.
Two. Installation method for wall-mounted massage bathtubs
1. Preparation
(1) According to the installation diagram and specified dimensions, install wooden or aluminum strips as support at the designated installation location.
(2) When attaching floor and wall tiles, the area and dimensions of the tiled surface must exceed the dimensions of the bathtub installation.
2. Electrical Planning
(1) When renovating a bathroom, it is necessary to reserve power conduits and junction boxes for the Jacuzzi, and the power supply must comply with the wiring diagram. It is essential to provide a dedicated circuit power connection and confirm that the power supply is 110 volts, allowing the wires to carry a current of 15 amps.
(2) The outlet for the cable and the motor should be 10cm higher than the ground, and a residual current device (RCD) should be installed in the distribution box. If a separate RCD for an independent circuit is not already installed, it must be installed in a suitable location, and should not be placed under a bathtub.
