| Model NO. | CX |
| Screw No. | Double-screw |
| Automation | Automatic |
| Computerized | Computerized |
| Certification | CE |
| Customized | Customized |
| Condition | New |
| After-sales Service | 24 Hours Service |
| Adapt Pipe Diameter | 0-160mm |
| Adapt Material | PVC |
| Colour | Customized |
| Saw Blade Diameter | 300mm |
| Saw Blade Speed | 2240rpm |
| Delivery Time | About 45 Working Days |
| Transport Package | Wooden Crate or PE Film |
| Specification | CE; ISO9001: 2000 |
| Trademark | chenxing |
| Origin | Jiangsu, China |
| HS Code | 8477800000 |
PVC Pipe Production Line(Two Cavity)
Product Description
The production line is developed with the advanced technology of West Europe by our company. The main machine is SJSZ 65/132 conical twin screw extruder is equipped with four-tube single-control stainless steel spraying calibration. It avoids waste condition when one tube is adjusted and the others are affected. The auto single-control four drawing machine and cutting machine are combined with the front four calibration technology to make operation more flexible. Let you enjoy economic benefit which is brought by spearate-control four-tube extruding.
The machine with energy efficient conical twin-screw extruder and through special mould one-time extrusion four piece of PVC pipe, effective energy conservation, can improve the production and efficiency, save land and labor costs.
Product Parameters
Pipe range
16-40mm
16-63mm
Extruder
SJZ51/105
SJZ65/132
Extruder power
18.5kw
37kw
Extrusion capacity
120kg/h
250kg/h
Max. Production speed
2 x 8m/min
2 x 10m/min
Detailed Photos
