| Model NO. | 5/32" to 3" inch |
| Type | Thermoplastic Pipe |
| Color | Transparent |
| Hollow | Hollow |
| Shape | Round |
| Usage | Drainpipe, Water Supply Pipe, Threading Pipe, Wire and Cable Pipe, Special Tube for Aquaculture |
| Working Temperature | -5℃ to +65℃ |
| Length | 10-50meters Can Be Customized |
| Wall Thickness | 1mm-7mm |
| Feature | Non-Toxic,Light,Flexible,Durable,Anti-Aging |
| Working Pressure | 2bar-5bar |
| Transport Package | Plastic Film, Woven Fabric, Customized Client |
| Specification | Can be customized |
| Trademark | Rongheng |
| Origin | China |
| HS Code | 3917390000 |
I. General Characteristics
The PVC transparent fluid hose is made from high-quality polymer-grade polyvinyl chloride (PVC) raw materials, through an improved formula and innovative process. It features outstanding transparency, flexibility and environmental resistance, making it an efficient solution in the field of fluid transmission.
The hose presents a crystal-clear visual effect with a light transmittance of 93%. The fluid state inside the hose is clearly visible. The material is both rigid and elastic, capable of withstanding repeated bending without turning white or cracking. The surface has strong anti-adhesion properties, making it easy to clean and maintain. The hose is lightweight and can be installed without the need for heavy tools; it can be operated manually.
II. Structure Design
The PVC transparent fluid hose adopts a single-layer homogeneous structure.
It is made of high-purity polyvinyl chloride (PVC) resin as the base material, combined with environmentally friendly plasticizers, heat stabilizers, and anti-freezing agents, etc., and is formed by a precise extrusion process.
The hose wall has uniform density, ensuring the stability of fluid transportation.
The internal surface is smooth, effectively reducing fluid resistance; the external surface retains high transparency while enhancing anti-scraping and wear resistance, avoiding surface scratches that may affect the observation effect.
The special formula enables the hose to maintain flexibility while having anti-ultraviolet and aging resistance properties, suitable for various indoor and outdoor environments.
III. Advantage Introduction
1. Ultra-transparent visibility:
Utilizing high-purity PVC raw materials and optical-grade additives, the light transmittance reaches 95%. The fluid state inside the hose is clearly visible, facilitating real-time monitoring of flow rate, bubbles, and impurities.
2. Weather-resistant and anti-aging:
After aging tests, it shows no obvious yellowing or brittleness even after outdoor use for 3 years.
3. Low-temperature toughness:
The working temperature range is -10℃ to 65℃. It remains flexible even in low-temperature conditions. It remains soft at -15℃ and can be bent and installed normally, avoiding the risk of cracking in winter. It does not soften or deform at high temperatures and is suitable for environments with temperature differences between the north and south.
4. Lightweight and durable design:
It is lighter in weight compared to other hoses, making it easy to handle and install.
Production Process
Product Parameters
Specification Selection
Category Standard Specifications
Inner Diameter Series Φ4 - Φ75
Wall Thickness Range 1.5 - 8.0mm (Customization with 0.5mm precision is supported)
Special Specifications Customization of color (transparent / semi-transparent / colored) is supported
I.D
O.D
L
W.P
B.P
Weight
inch
mm
mm
m/roll
bar
bar
g/m
5/32"
4
6
100
2
6
20
3/16"
5
7
100
2
6
25
1/4"
6
8
100
1.5
5
29
6
10
100
2
6
67
5/16"
8
10
100
1.5
5
38
8
12
100
2
6
84
3/8"
10
12
100
1.5
4
46
10
14
100
2
6
101
1/2"
12
15
50
1.5
4
85
12
16
50
2
6
118
5/8"
16
19
50
1
3
111
16
20
50
2
6
152
3/4"
19
22
50
1
3
130
19
23
50
1
3
178
1"
25
29
50
1
3
220
25
30
50
1
3
290
1-1/4"
32
38
50
1
3
440
1-1/2"
38
44
50
1
3
520
38
46
50
1
3
712
2"
50
58
50
1
2.5
910
2.5"
64
78
23
1
2.5
2170
3
75
91
20
1
2
3000
Application
Application Fields
1. Medical equipment:
Ventilator hose, infusion system, laboratory biological sample transfer.
2. Electronics industry:
Semiconductor cleaning solution delivery system, cooling fluid pipelines for precision instruments.
3. Aquaculture:
In the field of fishery and aquaculture, it serves as the hose for the water circulation system, transporting water and other fluids necessary for the cultivation process.
4. 3D Printing:
The transportation of inks, resins, etc. is carried out. The transparent nature makes it easy to observe the remaining amount and flow state of the consumables.
