Model NO.	C10800
Material	Red Copper
Shape	Round
Alloy	Non-alloy
Color	Red
Temper	Soft Anneal, Deep-Drawing Anneal, etc
Surfaces	Mill, Polished, Bright, Oiled, Hair Line,etc
Standards	ASTM, GB, ISO, DIN, BS, JIS, En, etc.
Diameter	<500mm, or as Requirement
Length	<3m, or as Requirement
Thickness	1mm~15mm, or as Requirment
Transport Package	Bundles or as Customer's Requirement
Trademark	ZYTC
Origin	China
HS Code	7409119000
Production Capacity	200tons/Month

ca

Product NameMuller Mandev 8mm 40mm C10800 Copper Pipe for Bus Bars StandardASTM, AISI, DIN, EN, GB, JIS, etc MaterialASTM B75/B75M-2020: C10800 MOQ300Kg PackageStandard export package, suited for all kinds of transport, or as required.  price termEXW, FOB, CFR, CIF, DDP, etc. ContactIf you have any questions, please feel free to contact me. We are sure your inquiry or requirements will get prompt attention.

GRADETECHNOLOGYTEMPER COPPER HOT ROLLEDM20 COLD ROLLEDO60,H01,H02,H04,H06,H08

ITEMSIZE PIPE/ TUBEOUT DIAMETER1mm~300mm WALL THICKNESS0.5mm~15mm LENGTH1000mm~3000mm, or as required

ASTM B75/75M-2020

Standard Specification for Seamless Copper Tube
This specification establishes the requirements for seamless round, rectangular, and square copper tube (UNS Nos. C10100, C10200, C10300, C10800, C12000, and C12200) suitable for general engineering applications. The material of manufacture shall be billets, cast bars, or tube. The tube shall be manufactured by hot- and cold-working processes, shall be cold drawn to the finished size and wall thickness, and shall be supplied in cold-drawn or annealed temper condition. The material shall conform to the chemical composition requirements prescribed for copper, phosphorus,  as determined by chemical analysis, and to the mechanical property requirements including tensile strength, yield strength, Rockwell hardness, and straightening. Requirements for grain size, electrical mass resistivity, and dimensions are specified. The following test methods are detailed: grain size, electrical resistivity, tensile and yield strength, and hardness tests, expansion test for round table, microscopical examination, test for hydrogen embrittlement, and nondestructive tests such as electromagnetic (eddy-current), hydrostatic, and pneumatic pressure tests.

C10800

C10800 copper is a lightly alloyed grade of copper, formulated for primary forming into wrought products. C10800 is the UNS number for this material. Additionally, the AFNOR (French) designation is Cu-b2. It can have a moderately low tensile strength among the wrought coppers in the database. H80 C10800 copper is C10800 copper in the H80 (hard drawn) temper. It has the second highest strength and second lowest ductility compared to the other variants of C10800 copper.

Chemical Composition

Copper UNS No.Type of Copper

C10100

Oxygen-free electronic

C10200

Oxygen-free without residual deoxidants

C10300

Oxygen-free, extra low phosphorus

C10400Oxygen-free, silver bearing C10500Oxygen-free, silver bearing C10700Oxygen-free, silver bearing

C10800

Oxygen-free, low phosphorus

C11000Electrolytic tough pitch C11300Silver-bearing tough pitch C11400Silver-bearing tough pitch C11600Silver-bearing tough pitch

C12000

Phosphorus deoxidized, low residual phosphorus

C12200

Phosphorus deoxidized, high residual phosphorus

Copper Alloy

Type(GB)(ISO)(ASTM)(EN)(JIS)(BS)(DIN) Red copperTU2Cu-OFC10100CW008AC1011C101OF-Cu T2Cu-FRHCC11000 C1100C101E-Cu58 TP2Cu-DHPC12200CW024AC1220C106SF-Cu TP1Cu-DLPC12000CW023AC1201 SW-Cu Sliver copperTAg0.1CuAg0.1C10400 C1040 CuAg0.1 BrassH90CuZn10C22000CW501LC2200CZ101CuZn10 H70CuZn30C26000CW505LC2600CZ106CuZn30 H68 C26200CW506LC2620 CuZn33 H65CuZn35C27000CW507LC2700CZ107CuZn36 H63CuZn37C27200CW508LC2720CZ108CuZn37 H62CuZn40C28000CW509LC2800CZ109  Tin-Bronze copperQSn4-0.3CuSn4C51100CW450KC5111PB101CuSn4 CuSn5C51000CW451KC5101 CuSn5 QSn6.5-0.1CuSn6C51900CW452KC5191PB103CuSn6 QSn8-0.3CuSn8C52100CW453KC5210 CuSn8 QSn6.5-0.4       Zn-white copperBZn18-18CuNi18Zn20C75200CW409JC7521NS106CuNi18Zn20 BZn18-26CuNi18Zn27C77000CW410JC7701NS107CuNi18Zn27 BZn15-20   C7541

Typical Uses

General Characteristics

Applications

Good Electrical and Thermal Conductivity

Good Electroplating Ability

Good Corrosion Resistance

Good Cold Forming and Deep Drawing Qualities

Perfect Soldering and Welding

Excellent Against Stress Corrosion Cracking

1.Fluid pipe           2. Power Plant       3. Structure pipe
4. High and low-pressure Boiler tube
5. Seamless steel tubes for petroleum cracking
6. Conduit pipe
7. Scaffolding pipe pharmaceutical and ship building
