| Model NO. | GYTS |
| Connection Structure | Stranded Loose Tube |
| Material Shape | Round Wire |
| Allowed Lateral Pressure | >1000(N/100mm) |
| Allowed Tensile Strength | 100N<1000N |
| Core | 2-256 Core |
| Certification | RoHS, ISO9001 |
| Sheath Material | HDPE/Hffr |
| Fiber Brand | Yofc/Corning/Sumitomo |
| Certifications | Ce/ISO9001/Tlc |
| Fiber Model | G657A/G652D |
| Transport Package | Wooden Drum |
| Specification | 2km/Drum or According to Customers Requirements |
| Trademark | JIANGHONG or OEM |
| Origin | Sichuan, China |
| HS Code | 8544700000 |
| Production Capacity | 5000000km |
SM G652D Optical Fiber Cable Armored Steel Tape HDPE MDPE Sheath GYTS 4Core Cable
DEscriptION
The product is to insert optical fiber into a loose tube made of high modulus material, filled with water-blocking compounds. A layer of polyethylene should be extruded outside the metal reinforced core. The loose tube and filling rope around the center strengthen the core winch to form a compact and round cable core. The gap in the cable core is filled with water blocking fillings. Two - sided coated plastic steel belt after longitudinal package extruded polyethylene sheathed cable.
FEATURES
Low loss and dispersion of optical fiber transmission;
Full cross section water-blocking structure to ensure water-blocking and moisture proof performance;
Double - sided coated plastic steel belt (PSP) to improve cable moisture resistance
APPLICATIONS
Duct and aerial
PERFORMANCE
