| Thickness | 5~50mm |
| Usage | Environmental Protection, Industral, Water Supply & Drainage |
| Product Categories | FRP Pipe |
| Molding Method | Filament Winding |
| Material | Fiberglass |
| Fiber Type | GFRP |
| Type | Polyester FRP |
| Pressure | Gravity, 0.6MPa, 1.0 MPa, 1.6 MPa |
| Stiffness | Sn5000, Sn7500, Sn10000 |
| Stanadard | Awwa C950 |
| Purpose | Drinking Water, Seawater |
| Transport Package | Seaworthy |
| Specification | DN15-DN4000mm |
| Trademark | JIUBO |
| Origin | China |
| HS Code | 3917290000 |
| Production Capacity | 100000m |
FRP pipe is a new kind of pipe material used for fluid transportation in recent years. Because of its excellent properties, it has been used extensively on the market. The reciprocal filament winding process has the advantages of high strength, reasonable jointing type, convenient installation, speedy test of the leakage test to the joint, it mainly be used for buried pipeline and long-distance transfer pipeline.
The length-fixed winding process is controlled by computer. Manufacture the liner on the mandrel as the same process of fiber glass winding pipe, then after the resin became hardened, make the structure layer by winding according to the designed linearity and thickness, and add the mixture of mortar and resin into the structure layer, finally, wind the outer protection layer.
The pipe is consisted of inner liner, interface, structural layer, and outer surface layer.
Inner liner corrosive resistance layer, Surfaces exposed to the chemical environment shall be resin-rich and reinforced with a 10 or 20 mil thick chemical surfacing mat (E- glass).
Interface layer is leakage proof layer, it be reinforced by minimum of three layers of 1.5 oz chopped strand mat.
Structural layer will be reinforced by continuous strand fiberglass roving and shall maintain a resin content of 20-40%. It is reinforcement for the inner lining layer and interface, resisting the foreign load to the pipe body and ensures the strength and stiffness of the pipe body.
The exterior surface shall consist of a chopped strand glass over which a resin-rich coating shall be applied.
1. Appearance
The inner surface of the FRP pipe should be smooth and even, no crack, delamination, pinhole, impurity, poor gel area and air bubble, the ends of the pipe should be even and uniform, no burr and exposed fiber.
2. Dimension
a. The tolerance for ovality of FRP pipe: when DN≤150 mm,adopt 2.0mm;when DN>150,adopt the bigger, 3.5mm or 1% of diameter of FRP pipe.
b. The tolerance for the length of the pipe is ±3.5mm.
c. For FRP pipe without flanges, the deviation of perpendicularity between the pipe end and the center line of the pipe: when DN≤600 mm,it is ±3.5mm;when DN>600 mm,it is ±5.0 mm.
d. Tolerance for angle of pipe end:when DN≤600 mm, it is 1°,when DN≥700mm,it is 1/2°
3. Mechanical properties
Mechanical properties of FRP product made with contact mould
(mm)
MPa
MPa
Mechanical properties of FRP product made with filament winding
5. The barcol hardness shall be tested according to the stipulation of GB3854,the tested value is not less than 40.
