One. Can the door closer be installed on a swing door?
Stylish doors can be installed with door closers. After installing a door closer on a stylish door, the door can be guaranteed to open and close accurately and promptly back to its initial position, resulting in enhanced sealing and insulation for the door.
Two. Installation instructions for the "Fashion Door Closer"
1、Installation instructions typically included with door locks.，Therefore, begin by reading the instructions.，Depending on the door's opening direction、Door strength and lock mechanism、Determine installation location based on the mounting dimensions between the hinge and the connecting hardware.。
2. According to the requirements for door closing force, the closing force can be adjusted by reversing the connecting seat by 180° or changing the connection position between the connecting rod and the connecting seat. The greater the adjustment of the distance between the connecting rod and the centerline of the hinges, the smaller the closing force; conversely, the closing force will be larger.
3. According to the location markings on the installation template, determine the location for the installation screws, then drill and tap the holes.
4、Install the door closer body using screws.
5、Install and secure the connecting seat.
6、Install the drive plate using screws.
7. Adjust the adjustment lever to be perpendicular to the door frame, then connect the connecting rod to the drive plate.
8. Don't forget to install the plastic cover, which can be used to collect any hydraulic oil that may leak from the door closer.
9. After installation, check that all fixing screws are securely tightened and there are no loose or unstable conditions. Open the door to its maximum opening position and check that the hinges and operating arm of the door closer do not collide or rub against the door or door frame.
